ABB - Installation Products TBM6266 - Die for BPLT62BSCR and BPLT6500BSCR Tool for 300 kcmil CU, 4/0 Al

ABB Installation Products TBM6266 Die for BPLT62BSCR and BPLT6500BSCR Tool for 300 kcmil CU, 4/0 Al

UPC: 786210360782


Documents & Media
Manufacturer Product Website

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

This ABB Die (SKU: TBM6266) is a specialized component designed for use with the BPLT62BSCR and BPLT6500BSCR installation tools. Its primary function is to facilitate the crimping of specific conductor sizes. Accurate and consistent crimps are essential for reliable electrical connections, ensuring conductivity and preventing failures. The TBM6266 die provides the precise dimensions required for these conductor types, enabling the BPLT62BSCR and BPLT6500BSCR tools to achieve proper mechanical connections. When paired with the appropriate ABB tool, this die supports the installation of electrical infrastructure where these conductor sizes are specified. Reliability in electrical connections is paramount, and the correct die ensures the tool performs as intended for the specified conductor materials and sizes. This product falls under the UNSPSC code 27112820, indicating its classification within electrical equipment and accessories.
  • Designed for ABB BPLT62BSCR and BPLT6500BSCR installation tools
  • Ensures precise and reliable crimps for electrical connections
  • Part of ABB Installation Products

Specifications

Application
Crimping connectors
Color
Black
Series
BPLT62BSCR, BPLT6500BSCR
Size
300 kcmil CU, 4/0 Al
Special Features
Color-Keyed system have colored bands or colored dots that correspond to color markings on the dies
Type
Die
Package Dimensions (L x W x H)
4.12 IN x 1.25 IN x 0.5 IN
Package Dimensions (L x W x H)
10.4648 cm x 3.175 cm x 1.27 cm
Package Weight (Imperial)
0.0300 L
Package Weight (Metric)
0.0140 kg
