ABB - Installation Products TA 5-1010 K - Tin-Plated Copper Pad with Adapter and 1-14 x 2 inch long Threaded Stud, Black PVC Encapsulated. Bar 7 inch x 1.75 inch x .375 inch Thick. Includes Cap and Steel 1-14 inch Jam Nut. Stud and Adapter Silver Brazed in place on Pad.
ABB - Installation Products

TA 5-1010 K

UPC: 783786753772

Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 10

Multiplier: 10

*Contact for lower quantities*

Overview

The ABB TA 5-1010 K is a robust tin-plated copper pad designed for secure electrical connections. This unit features a black PVC encapsulation for enhanced durability and protection. The pad measures 7 inches in length, 1.75 inches in width, and 0.375 inches in thickness, providing a substantial surface area for reliable contact. Integrated into the pad is a 1-14 x 2 inch long threaded stud, silver brazed in place for a strong, permanent bond. An accompanying adapter is also silver brazed to the pad, ensuring precise alignment and secure mounting. The package includes a cap and a steel 1-14 inch jam nut, facilitating straightforward installation and adjustment. The silver brazing process used for attaching the stud and adapter to the pad guarantees high conductivity and mechanical integrity, crucial for demanding industrial applications. This component, part of the ABB Installation Products line, is identified by SKU TA 5-1010 K and UNSPSC code 39121443. Its construction from tin-plated copper offers excellent corrosion resistance and electrical conductivity, making it suitable for environments where reliable power distribution is paramount. The black PVC encapsulation adds an extra layer of insulation and protection against environmental factors, further extending the product's service life. The inclusion of the jam nut and cap simplifies the assembly process, allowing for quick and secure fastening in various electrical configurations. The specific dimensions and robust materials ensure this pad can withstand significant mechanical stress and electrical loads, making it a dependable choice for power distribution and grounding applications within industrial settings.
  • Tin-plated copper pad for superior conductivity and corrosion resistance
  • Black PVC encapsulated for enhanced durability and protection
  • Silver-brazed 1-14 x 2 inch threaded stud and adapter for secure connections
  • Pad dimensions: 7 inch x 1.75 inch x 0.375 inch
  • Includes cap and steel 1-14 inch jam nut for easy installation

Specifications

Connection
Mechanical
Finish
Tin Plated
Insulation
False
Material
Copper
Size
7 inch x 1.75 inch x .375 inch Thick
Type
Adapter Pad
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
2.5300 L
Package Weight (Metric)
1.1480 kg
Fuse Module, P-LS2B, P-LS2C

K8595177A

Fuse Module, P-LS2B, P-LS2C
HPE Synergy 6820C 25/50Gb Converged Network Adapter

P02054-B21

HPE Synergy 6820C 25/50Gb Converged Network Adapter
Tin-Plated Copper Pad with Adapter and 5/8-11 x 2 inch long Threaded Stud, Black PVC Encapsulated. Bar 6-13/32 inch x 1-3/4 inch x 3/8 inch Thick. Includes Cap and Steel 5/8-11 inch Jam Nut. Stud and Adapter Silver Brazed in place on Pad.

TA 5-5858 K

Tin-Plated Copper Pad with Adapter and 5/8-11 x 2 inch long Threaded Stud, Black PVC Encapsulated. Bar 6-13/32 inch x 1-3/4 inch x 3/8 inch Thick. Includes Cap and Steel 5/8-11 inch Jam Nut. Stud and Adapter Silver Brazed in place on Pad.
