ABB - Installation Products T38TB - 1 Inch Form 8 (T) Conduit Body, Body Material Gray Iron with Zinc Plating and Baked on Epoxy Powder Coat with BlueKote Internal Coating for Use with Rigid/IMC Conduit

ABB Installation Products T38TB 1 Inch Form 8 (T) Conduit Body, Body Material Gray Iron with Zinc Plating and Baked on…

UPC: 786210166124


Documents & Media
Specification SheetManufacturer Product Website

Contact for Pricing

Minimum Qty: 2

Multiplier: 2

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB T38TB is a 1-inch Form 8 (T) conduit body constructed from durable gray iron. This robust construction is enhanced with a zinc plating and a baked-on epoxy powder coat finish, providing excellent resistance to corrosion and environmental degradation. A key feature of this conduit body is its BlueKote internal coating, specifically designed to facilitate wire pulling and protect conductors during installation and operation. This internal coating significantly reduces friction, making it easier to pull wires through the conduit system, especially in complex or long runs. The Form 8 configuration, also known as a Type T, offers a "T" shaped opening, allowing for changes in conduit direction or the introduction of a branch conduit run. This makes it suitable for applications requiring branching or directional changes within rigid or Intermediate Metal Conduit (IMC) systems. The 1-inch size accommodates standard 1-inch rigid and IMC conduit, ensuring compatibility with a wide range of electrical installations. Manufactured by ABB Installation Products, the T38TB conduit body is engineered for reliability in various industrial and commercial settings. Its material composition and protective coatings ensure longevity and performance, making it a dependable choice for protecting electrical wiring and facilitating conduit system assembly. The gray color of the exterior finish provides a neutral aesthetic suitable for most industrial environments. Key Specifications: * **Manufacturer:** ABB - Installation Products * **SKU:** T38TB * **Conduit Size:** 1 Inch * **Configuration:** Form 8 (T) * **Body Material:** Gray Iron * **Exterior Finish:** Zinc Plating with Baked on Epoxy Powder Coat * **Internal Coating:** BlueKote * **Conduit Compatibility:** Rigid/IMC Conduit * **Color:** Gray This conduit body is ideal for electrical contractors and facility maintenance professionals who require a dependable and efficient solution for managing conduit runs and protecting electrical circuits. The combination of durable materials and specialized internal coating simplifies installation and enhances the overall integrity of the electrical system.
  • 1 Inch Form 8 (T) conduit body for Rigid/IMC conduit
  • Durable gray iron construction with zinc plating
  • Baked-on epoxy powder coat for enhanced corrosion resistance
  • BlueKote internal coating for easier wire pulling
  • ABB Installation Products quality and reliability

Specifications

Application
Conduit Bodies are Installed In Conduit Systems to Connect Sections, Act As Pull Outlets When Conductors are Being Installed and Provide Easy Access for Splices In Branch Conductors
Finish
Zinc Plated with Epoxy Powder Coat
Form
Form 8
Hub Size
1
Material Quality
Gray Iron
Special Features
BlueKote Teflon Based Internal Finish Provides a Slick, Easy-Glide Internal Surface Which Significantly Lowers the Amount of Force Necessary to Pull Wires
Standard
UL E2969, CSA
Package Dimensions (L x W x H)
8.25 IN x 5.25 IN x 4.25 IN
Package Dimensions (L x W x H)
20.955 cm x 13.335 cm x 10.795 cm
Package Weight (Imperial)
2.7000 L
Package Weight (Metric)
1.2250 kg
PVC Coated Sealing Fitting for Hazardous Locations, EZD Series, Pipe Size 1 Inch/27 Metric, Gray

EZD311-G

PVC Coated Sealing Fitting for Hazardous Locations, EZD Series, Pipe Size 1 Inch/27 Metric, Gray
1-1/4 Inch Form 7 (T) Conduit Body, Body Material Gray Iron with Zinc Plating and Baked on Epoxy Powder Coat with BlueKote Internal Coating for Use with Rigid/IMC Conduit

T47

1-1/4 Inch Form 7 (T) Conduit Body, Body Material Gray Iron with Zinc Plating and Baked on Epoxy Powder Coat with BlueKote Internal Coating for Use with Rigid/IMC Conduit
1-1/4 Inch Form 8 (T) Conduit Body, Body Material Gray Iron with Zinc Plating and Baked on Epoxy Powder Coat with BlueKote Internal Coating for Use with Rigid/IMC Conduit

T448

1-1/4 Inch Form 8 (T) Conduit Body, Body Material Gray Iron with Zinc Plating and Baked on Epoxy Powder Coat with BlueKote Internal Coating for Use with Rigid/IMC Conduit
1-1/2 Inch Form 7 (T) Conduit Body, Body Material Gray Iron with Zinc Plating and Baked on Epoxy Powder Coat with BlueKote Internal Coating for Use with Rigid/IMC Conduit

T57

1-1/2 Inch Form 7 (T) Conduit Body, Body Material Gray Iron with Zinc Plating and Baked on Epoxy Powder Coat with BlueKote Internal Coating for Use with Rigid/IMC Conduit
1-1/2 Inch Form 8 (T) Conduit Body, Body Material Gray Iron with Zinc Plating and Baked on Epoxy Powder Coat with BlueKote Internal Coating for Use with Rigid/IMC Conduit

T58

1-1/2 Inch Form 8 (T) Conduit Body, Body Material Gray Iron with Zinc Plating and Baked on Epoxy Powder Coat with BlueKote Internal Coating for Use with Rigid/IMC Conduit
2 Inch Form 7 (T) Conduit Body, Body Material Gray Iron with Zinc Plating and Baked on Epoxy Powder Coat with BlueKote Internal Coating for Use with Rigid/IMC Conduit

T67

2 Inch Form 7 (T) Conduit Body, Body Material Gray Iron with Zinc Plating and Baked on Epoxy Powder Coat with BlueKote Internal Coating for Use with Rigid/IMC Conduit
3 Inch Form 8 (T) Conduit Body, Body Material Gray Iron with Zinc Plating and Baked on Epoxy Powder Coat with BlueKote Internal Coating for Use with Rigid/IMC Conduit

T88TB

3 Inch Form 8 (T) Conduit Body, Body Material Gray Iron with Zinc Plating and Baked on Epoxy Powder Coat with BlueKote Internal Coating for Use with Rigid/IMC Conduit
2-1/2 Inch Form 8 (T) Conduit Body, Body Material Gray Iron with Zinc Plating and Baked on Epoxy Powder Coat with BlueKote Internal Coating for Use with Rigid/IMC Conduit

T78

2-1/2 Inch Form 8 (T) Conduit Body, Body Material Gray Iron with Zinc Plating and Baked on Epoxy Powder Coat with BlueKote Internal Coating for Use with Rigid/IMC Conduit

Frequently Asked Questions

Do Form 8 covers for T38TB include gaskets?

Yes, all Form 8 covers, which are used with T38TB, include Neoprene gaskets.

What standards does the T38TB conduit body comply with?

The conduit bodies comply with UL Standard 514A, 514B, Fed. Spec. W-C-586D, and CSA Standard C22.2 No. 18.

What is the hub size of the T38TB conduit body?

The T38TB conduit body has a hub size of 1 inch.

Is the T38TB conduit body compatible with other brands?

T&B Form 8 bodies and covers, including T38TB, are interchangeable with other manufacturers’ Form 8 bodies and covers.

What is the external finish of the T38TB conduit body?

The T38TB iron conduit body has a zinc-plating with an aluminum acrylic coating.

What is the internal coating of the T38TB conduit body?

T38TB, as a Form 8 iron body, features a BlueKote® internal coating, which is PTFE-based, for easier wire pulling.

What material is the T38TB conduit body made from?

The T38TB is a Form 8 iron conduit body, made from sand-cast class 30 gray iron alloy.

What is the primary purpose of T38TB conduit bodies?

Conduit bodies like T38TB connect conduit sections, act as pull outlets, provide access for splices, make 90° bends, and serve as mounting outlets for wiring devices.

What is the internal coating of the T38TB conduit body?

T38TB, as a Form 8 iron body, features a BlueKote® internal coating, which is PTFE-based, for easier wire pulling.

What standards does the T38TB conduit body comply with?

The conduit bodies comply with UL Standard 514A, 514B, Fed. Spec. W-C-586D, and CSA Standard C22.2 No. 18.
