ABB - Installation Products SP10DS - Short Stud Double Service Post Connectors for Conductors 500 - 3/0 Stranded Stud Size 3/4 - 10 x 1 1/4

ABB Installation Products SP10DS Short Stud Double Service Post Connectors for Conductors 500 - 3/0 Stranded Stud Size…

UPC: 783786485062


Documents & Media
Specification SheetManufacturer Product Website

Contact for Pricing

Minimum Qty: 48

Multiplier: 48

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB SP10DS Short Stud Double Service Post Connector is designed for reliable electrical connections in industrial applications. This connector accommodates stranded conductors ranging from 500 kcmil down to 3/0 AWG, providing flexibility for various wiring needs. It features a 3/4-inch stud size, suitable for standard mounting hardware, and includes two 10 x 1 1/4 inch studs for secure conductor termination. The double service post design allows for multiple conductor connections at a single point, simplifying complex wiring configurations and reducing the need for additional components. Manufactured by ABB - Installation Products, the SP10DS ensures dependable performance in electrical distribution systems. Its robust construction is built for the demands of industrial environments. This connector is essential for ensuring safe and efficient power distribution where multiple conductors need to be joined or terminated to a common bus or terminal. The specific dimensions and stud sizes are critical for compatibility with existing infrastructure and for ensuring proper torque and contact resistance. The SP10DS is a practical solution for power distribution panels, substations, and heavy-duty electrical equipment. Its UNSPSC code is 39121613.
  • Accommodates stranded conductors from 500 kcmil to 3/0 AWG
  • Features a 3/4-inch main stud size
  • Includes two 10 x 1 1/4 inch termination studs
  • Double service post design for multiple connections
  • Manufactured by ABB - Installation Products

Specifications

Application
For copper to copper connections, for grounding of steel structures or transformers using one or two cables, for tapping one or two cables from bus bar
Conductor Material
Copper
Conductor Size
3/0 AWG - 500kcmil
Size
3/4 - 10 x 1 1/4
Special Features
Hex design bolts are machined from high-conductivity bronze alloy
Standard
UL E9809
Type
Mechanical Grounding
Package Dimensions (L x W x H)
8.25 IN x 7.13 IN x 6.25 IN
Package Dimensions (L x W x H)
20.955 cm x 18.1102 cm x 15.875 cm
Package Weight (Imperial)
1.1200 L
Package Weight (Metric)
0.5080 kg
