ABB - Installation Products SHF324SHT12G - Hot-dipped galvanized steel fitting 3-5/8 inches side rail height 24 inches width solid trough horizontal tee 12 inches radius ground hole

ABB Installation Products SHF324SHT12G Hot-dipped galvanized steel fitting 3-5/8 inches side rail height 24 inches width solid…

UPC: 785055639725


Documents & Media
Video ClipManufacturer Product Website

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

This ABB Installation Products horizontal tee fitting, SKU SHF324SHT12G, is constructed from hot-dipped galvanized steel, providing robust corrosion resistance for industrial applications. Designed for cable management systems, this fitting features a 3-5/8 inch side rail height and a 24-inch width, ensuring ample capacity for various cable and conduit types. The solid trough design offers complete enclosure and protection for the contents. Its horizontal orientation facilitates efficient routing of services within a cable tray system. The tee configuration allows for a 90-degree branch connection, enabling complex network layouts. A 12-inch radius is incorporated into the design, which is crucial for maintaining cable integrity by preventing sharp bends that could damage conductors. Additionally, a ground hole is integrated for proper electrical grounding, a critical safety feature in industrial settings. This fitting is suitable for environments where durability and reliable cable support are paramount. The hot-dipped galvanization process ensures long-term performance and protection against environmental factors. Manufacturer: ABB - Installation Products. SKU: SHF324SHT12G. UNSPSC Code: 39131705.
  • Hot-dipped galvanized steel construction for corrosion resistance
  • 3-5/8 inch side rail height and 24 inch width for ample capacity
  • Solid trough design for complete cable protection
  • Horizontal tee configuration for 90-degree branching
  • 12 inch radius and integrated ground hole for safety and integrity

Specifications

Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
41.4800 L
Package Weight (Metric)
18.8150 kg
