ABB - Installation Products RA18-250FL - Nylon Insulated Female Disconnect 250 Series Wire Range 22-18 STR Tabe Size 0.250 x 0.032 Color Red

ABB Installation Products RA18-250FL Nylon Insulated Female Disconnect 250 Series Wire Range 22-18 STR Tabe Size 0.250 x…

UPC: 786210358031


Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 100

Multiplier: 100

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB RA18-250FL is a Nylon Insulated Female Disconnect designed for reliable electrical connections. This specific model is part of the 250 Series, indicating its compatibility with standard 250 series male terminals. It is engineered to accommodate wire ranges from 22 to 18 AWG (American Wire Gauge) stranded wire, ensuring a secure and proper fit for a variety of electrical wiring applications. The disconnect features a tab size of 0.250 inches by 0.032 inches, a common dimension for this series. Constructed with durable nylon insulation, the RA18-250FL provides electrical isolation and protection, crucial for safe operation in industrial settings. The vibrant red color coding clearly identifies the wire gauge range (22-18 AWG), facilitating quick and accurate identification during installation and maintenance, thereby minimizing the risk of errors. This feature is particularly valuable in complex electrical systems where rapid component recognition is essential for efficiency and safety.
  • Nylon insulated female disconnect for secure electrical connections.
  • Designed for 22-18 AWG stranded wire range.
  • Features a standard 250 Series tab size (0.250 x 0.032 inches).
  • Color-coded red for easy identification of wire gauge.
  • Manufactured by ABB - Installation Products for reliable performance.

Specifications

Color
Red
Finish
Tin Plated
Insulation
Yes
Material
Nylon
Series
250 Series
Size
0.250 x 0.032
Standard
UL E66716
Type
Nylon Insulated Female Disconnect
Voltage Rating
300 kV
Wire Size
22-18 AWG
Package Dimensions (L x W x H)
2.5 IN x 1.3 IN x 3.5 IN
Package Dimensions (L x W x H)
6.35 cm x 3.302 cm x 8.89 cm
Package Weight (Imperial)
0.0010 L
Package Weight (Metric)
0.0010 kg
Nylon insulated double crimp female disconnect 250 Series, Wire range 22-16, Red, Canister of 15 disconnects

TNF18-250FDD-XV

Nylon insulated double crimp female disconnect 250 Series, Wire range 22-16, Red, Canister of 15 disconnects
22-18 AWG Nylon Insulated Ring 1/4" Stud, 100 Per Pack

R22-14N

22-18 AWG Nylon Insulated Ring 1/4" Stud, 100 Per Pack
Insulated Nylon Female - 110 Series Disconnects For Wire Range 16-14 Length 0.75 Blue Mylar Tape

RB10M

Insulated Nylon Female - 110 Series Disconnects For Wire Range 16-14 Length 0.75 Blue Mylar Tape
Nylon Insulated Female Disconnect, Length .75 Inches, .15 Width, Maximum Insulation .135, Tab Size .110x.020, Wire Range #16-#14 AWG, Color Blue, Copper, Tin Plated, On Mylar Tape, 1,000 Pack

RB11M

Nylon Insulated Female Disconnect, Length .75 Inches, .15 Width, Maximum Insulation .135, Tab Size .110x.020, Wire Range #16-#14 AWG, Color Blue, Copper, Tin Plated, On Mylar Tape, 1,000 Pack
Insulation Piercing Magnet Wire Female Disconnect, Length .79 Inches, Width .25 Inches, Length of Teeth .32 Inches, Width of Teeth .16 Inches, Tab Size .250 x .032, Wire Range #24 AWG - #15 AWG 404 Circular Mil Area - 4,100 Circular Mil Area, Copper Alloy, Tin Plated

22LF01

Insulation Piercing Magnet Wire Female Disconnect, Length .79 Inches, Width .25 Inches, Length of Teeth .32 Inches, Width of Teeth .16 Inches, Tab Size .250 x .032, Wire Range #24 AWG - #15 AWG 404 Circular Mil Area - 4,100 Circular Mil Area, Copper Alloy, Tin Plated
Insulation Piercing Magnet Wire Female Disconnect, Length .91 Inches, Width .25 Inches, Length of Teeth .45 Inches, Width of Teeth .25 Inches, Tab Size .250 x .032, Wire Range #16 AWG - #12 AWG 2,580 Circular Mil Area - 12,330 Circular Mil Area, Copper Alloy, Tin Plated

22LF06

Insulation Piercing Magnet Wire Female Disconnect, Length .91 Inches, Width .25 Inches, Length of Teeth .45 Inches, Width of Teeth .25 Inches, Tab Size .250 x .032, Wire Range #16 AWG - #12 AWG 2,580 Circular Mil Area - 12,330 Circular Mil Area, Copper Alloy, Tin Plated
Insulation Piercing Magnet Wire Male Disconnect, Length .91 Inches, Width .25 Inches, Length of Teeth .45 Inches, Width of Teeth .25 Inches, Tab Size .250 x .032, Wire Range #16 AWG - #12 AWG 2,580 Circular Mil Area - 12,330 Circular Mil Area, Copper Alloy, Tin Plated

22LM06

Insulation Piercing Magnet Wire Male Disconnect, Length .91 Inches, Width .25 Inches, Length of Teeth .45 Inches, Width of Teeth .25 Inches, Tab Size .250 x .032, Wire Range #16 AWG - #12 AWG 2,580 Circular Mil Area - 12,330 Circular Mil Area, Copper Alloy, Tin Plated
Insulated Vinyl Female Disconnect, For Wire Range 22-18, Red

18RA-250FL

Insulated Vinyl Female Disconnect, For Wire Range 22-18, Red
