ABB - Installation Products PTC 750-6536 - Tin Plated Copper Tapered Compression Splices - solid center oil stop, wire size 750 kcmil CU, with Milled Slot Section on 800 kcmil Segmental CU side. Installing Dies 106, 24, 1 5/16. Length 4-9/32 inch. Barrel Length 2-1/16 inch. Slotted Side marked with Orange Ink.

ABB Installation Products PTC 750-6536 Tin Plated Copper Tapered Compression Splices - solid center oil stop, wire size 750…

UPC: 783786821020


Documents & Media
Manufacturer Product Website

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

This ABB Tin Plated Copper Tapered Compression Splice (SKU: PTC 750-6536) is engineered for reliable electrical connections in demanding industrial applications. Designed for solid center oil stop functionality, it ensures a secure and insulated joint. The splice accommodates a 750 kcmil copper (CU) conductor on one side and an 800 kcmil segmental copper (CU) conductor on the other. A key feature is the milled slot section on the 800 kcmil segmental CU side, facilitating a robust mechanical and electrical connection. Installation requires specific tooling, including installing dies 106, 24, and 1 5/16. The overall length of the splice is 4-9/32 inches, with a barrel length of 2-1/16 inches. For clear identification during installation, the slotted side is marked with orange ink. This component is part of ABB's extensive Installation Products catalog, known for its quality and performance in electrical infrastructure. Key Specifications: - Manufacturer: ABB - Installation Products - SKU: PTC 750-6536 - Conductor Size 1: 750 kcmil CU (Solid Center) - Conductor Size 2: 800 kcmil Segmental CU (Milled Slot Section) - Features: Solid center oil stop, Milled slot section - Installation Dies: 106, 24, 1 5/16 - Length: 4-9/32 inch - Barrel Length: 2-1/16 inch - Marking: Orange ink on slotted side - UNSPSC Code: 39121449
  • Tin Plated Copper Tapered Compression Splice
  • Accommodates 750 kcmil CU (Solid Center) and 800 kcmil Segmental CU
  • Features solid center oil stop for enhanced insulation
  • Milled slot section on 800 kcmil Segmental CU side for secure connection
  • Slotted side marked with orange ink for easy identification

Specifications

Application
High Voltage, Oil, Harsh Enviroments
Conductor Range
750 kcmil
Connection
Compression
Environmental Conditions
Harsh Environments
Finish
Tin-Plated
Insulation
None
Material
Copper
Number Of Conductors
2
Size
Length 4.280 inches
Special Features
Made from Electrolytic Seamless Copper Tubing for High Conductivity and Minimal Voltage Drop. Tapered Ends Enable use in High-Voltage Installations up to 69 kV. Tin-Plated to Resist Corrosion and Extend Shelf Life. Solid Center that Prevents Oil Seepage
Type
Compression Splice Service Entrance Insulated
Package Dimensions (L x W x H)
7.5 IN x 6 IN x 6.5 IN
Package Dimensions (L x W x H)
19.05 cm x 15.24 cm x 16.51 cm
Package Weight (Imperial)
0.6600 L
Package Weight (Metric)
0.2990 kg
2 Hole Long Barrel Copper Compression Lug for Flexible Copper Cable 750 MCM - 1/2" Bolt Compression lugs for flexible copper cables are connects that have a gentle, continuous flared end to ensure ease of cable insertion of flexible and extra flexible cables such as locomotive, welding, mining cable and more. The flared end also reduces pressure on the cable strands after installation and protects them from chafing and breakage as a result of cable movement. Tin-plated for corrosion resistance. Rated 600 volts for copper cables only. Single mounting hole.

L750NB

2 Hole Long Barrel Copper Compression Lug for Flexible Copper Cable 750 MCM - 1/2" Bolt Compression lugs for flexible copper cables are connects that have a gentle, continuous flared end to ensure ease of cable insertion of flexible and extra flexible cables such as locomotive, welding, mining cable and more. The flared end also reduces pressure on the cable strands after installation and protects them from chafing and breakage as a result of cable movement. Tin-plated for corrosion resistance. Rated 600 volts for copper cables only. Single mounting hole.
Copper Two-Way Splice - Heavy-Duty, 750 kcmil Wire, Tin Plated, Die Code 112

53523

Copper Two-Way Splice - Heavy-Duty, 750 kcmil Wire, Tin Plated, Die Code 112
Panduit BS18-C Non-Insulated Butt Splice

BS18-C

Panduit BS18-C Non-Insulated Butt Splice
Copper Tin-Plated Tees, main 1000, tap 1000. 9-1/2 inch wide x 4-1/2 inch tall, 1-1/2 inch thick. Dies 125 27 1 1/2. 1000 kcmil Copper. Silver Brazed Tap. Dimpled.

1000 T 1000

Copper Tin-Plated Tees, main 1000, tap 1000. 9-1/2 inch wide x 4-1/2 inch tall, 1-1/2 inch thick. Dies 125 27 1 1/2. 1000 kcmil Copper. Silver Brazed Tap. Dimpled.
Copper Tin-Plated Tees, main 600, tap 600. 600 MCM Copper. Dies 96 22 1 1/8-1. 7-1/4 inch Wide with Brazed Tap 2-11/16 inch. Dimpled Main.

600 T 600

Copper Tin-Plated Tees, main 600, tap 600. 600 MCM Copper. Dies 96 22 1 1/8-1. 7-1/4 inch Wide with Brazed Tap 2-11/16 inch. Dimpled Main.
Copper Compression Splice, 500 Compact Copper, 4.687 inch long, with Center Stop. Dies H, 87, 251.

C 500 CPTCS

Copper Compression Splice, 500 Compact Copper, 4.687 inch long, with Center Stop. Dies H, 87, 251.
Tin Plated Copper Straight Oil-Stop Splice, wire size #1 Stranded CU. Installing Dies 3/8, 11, TB, 37, 276. Length 2-7/8 inch.

PC 1-HM

Tin Plated Copper Straight Oil-Stop Splice, wire size #1 Stranded CU. Installing Dies 3/8, 11, TB, 37, 276. Length 2-7/8 inch.
Aluminum Tapered Splices - common die series - TU, 52, BG, 243. Wire size 1 Stranded AL-CU, 1/0 Solid. Length 3 inch. Outside diameter 5/8 inch. Oil Stop. Oxide Inhibitor. Red Caps.

SATC 1

Aluminum Tapered Splices - common die series - TU, 52, BG, 243. Wire size 1 Stranded AL-CU, 1/0 Solid. Length 3 inch. Outside diameter 5/8 inch. Oil Stop. Oxide Inhibitor. Red Caps.
