ABB - Installation Products PTC 2000 - Tin Plated Copper Tapered Compression Splices - solid center oil stop, wire size 2000 kcmil CU. Installing Dies 175, 34, 2, 2 1/8. Length 8-1/4 inch. Outside Diameter 2-1/8 inch. Barrel Length 3-11/16 inch.
ABB - Installation Products

PTC 2000

UPC: 075114293655

Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 5

Multiplier: 5

*Contact for lower quantities*

Overview

ABB Installation Products PTC 2000 is a tin-plated copper tapered compression splice engineered for robust performance in demanding electrical applications. Specifically designed for solid center oil-stop configurations, this splice is intended for use with 2000 kcmil copper conductors. The PTC 2000 ensures a secure, low-resistance connection, critical for high-current scenarios encountered in power distribution networks, substations, and extensive industrial wiring systems. Its overall length measures 8-1/4 inches, and it features an outside diameter of 2-1/8 inches, dimensions that are optimized to accommodate large conductors while maintaining essential mechanical integrity throughout the connection. The barrel of the splice extends to a length of 3-11/16 inches, providing a substantial area for compression. This ample barrel length is crucial for achieving reliable crimping when utilized with compatible ABB installing dies, specifically those in sizes 175, 34, 2, and 2-1/8. The tin plating applied to the copper construction serves to significantly enhance corrosion resistance, making the PTC 2000 a suitable choice for installations in outdoor environments and other harsh conditions where exposure to moisture and contaminants is a concern. The inherent compression design of this splice eliminates the necessity for traditional joining methods such as soldering or welding, thereby contributing to reduced installation time and associated labor expenses. This splice is manufactured to meet established industry standards for both electrical conductivity and mechanical strength, thereby guaranteeing sustained long-term performance in critical infrastructure projects. It is particularly well-suited for applications within the utility sector, renewable energy installations, and heavy industrial settings where the utmost reliability in high-current operations is a paramount requirement.
  • Tin-plated copper construction for corrosion resistance
  • Designed for 2000 kcmil solid copper conductors
  • Oil-stop feature prevents moisture ingress
  • Compatible with ABB installing dies (175, 34, 2, 2-1/8)
  • 8-1/4" length, 2-1/8" OD, 3-11/16" barrel length

Specifications

Conductor Range
2000 kcmil
Connection
Compression
Finish
Tin Plated
Insulation
None
Material
Copper
Number Of Conductors
2
Special Features
Oil Stop
Type
Compression Splice Service Entrance Insulated
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
4.2500 L
Package Weight (Metric)
1.9280 kg
