ABB - Installation Products PGH39 - Copper Type PGH - Center Bolt Parallel Groove Hot Tap Clamps for wire range Main AWG 2/0 Stranded - 8 Solid, Main ASCR. For use with copper conductor only. Has Oxide Inhibitor.

ABB Installation Products PGH39 Copper Type PGH - Center Bolt Parallel Groove Hot Tap Clamps for wire range Main AWG 2/0…

UPC: 783786850020

Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 25

Multiplier: 25

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB PGH39 Copper Type PGH Center Bolt Parallel Groove Hot Tap Clamp (SKU: PGH39) is a specialized connector designed for copper conductors only, ensuring reliable electrical connections in parallel groove applications. This clamp accommodates a wire range from 2/0 AWG stranded to 8 AWG solid, as well as ASCR conductors, making it versatile for medium to heavy-duty electrical installations. The center bolt design provides secure clamping force, minimizing resistance and heat buildup at the connection point. The inclusion of an Oxide Inhibitor helps prevent corrosion, extending the lifespan of the connection and maintaining electrical integrity over time. Unlike standard parallel groove clamps, the PGH39 is optimized for copper conductors, reducing the risk of galvanic corrosion when paired with compatible materials. It is ideal for hot tap applications where live-line connections are required, such as in utility, industrial, or commercial power distribution systems. The clamp’s robust construction ensures mechanical strength and durability, while its compact design allows for efficient installation in tight spaces. Compliance with industry standards ensures safe and reliable performance in high-current applications. For copper conductor systems requiring a dependable, corrosion-resistant parallel groove clamp, the ABB PGH39 delivers consistent results.
  • Designed for copper conductors only (2/0 Stranded to 8 Solid AWG, ASCR compatible)
  • Center bolt parallel groove design for secure, low-resistance connections
  • Includes Oxide Inhibitor to prevent corrosion and extend connection lifespan
  • Ideal for hot tap applications requiring live-line connections
  • Manufactured by ABB - Installation Products (SKU: PGH39)

Specifications

Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
0.5500 L
Package Weight (Metric)
0.2500 kg
