ABB - Installation Products NPG-M321B - Quick Connect Cable Gland, Thread Size M32, Cable Range 15 to 21mm, Thread Length 9mm, Nylon, Black

ABB Installation Products NPG-M321B Quick Connect Cable Gland, Thread Size M32, Cable Range 15 to 21mm, Thread Length 9mm…

UPC: 786210137858


Documents & Media
Installation InstructionsSpecification SheetManufacturer Product Website

Contact for Pricing

Minimum Qty: 5

Multiplier: 5

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB NPG-M321B Quick Connect Cable Gland is a nylon-based cable entry solution designed for M32 metric threads, providing secure and rapid installation for cables ranging from 15 to 21mm in diameter. This cable gland features a 9mm thread length, ensuring compatibility with standard enclosure panels and equipment mounting requirements. The black nylon construction delivers reliable mechanical protection and electrical insulation, making it suitable for indoor and outdoor applications where environmental resistance is required. Key specifications include a thread size of M32, optimized for use with matching metric entry points in control panels, junction boxes, and machinery housings. The quick-connect design eliminates the need for additional tools, reducing installation time by up to 60% compared to traditional gland types. This feature is particularly valuable in high-volume production environments or maintenance scenarios where downtime must be minimized.
  • M32 metric thread size for standard industrial enclosures
  • Quick-connect design for tool-free installation (up to 60% faster than traditional glands)
  • Cable range: 15 to 21mm diameter
  • Thread length: 9mm for compatibility with standard panel thicknesses
  • Nylon construction with UV, oil, and chemical resistance
  • Black color for visibility and industrial aesthetics
  • Manufactured by ABB Installation Products (SKU: NPG-M321B)

Specifications

Application
General purpose, Ideal for Panel building and Volume Installers
Color
Black
Conductor Range
15 to 21 Millimeters
Material
Nylon
Material Quality
Nylon
Operating Temperature, Maximum
212 F
Operating Temperature, Maximum
100 C
Operating Temperature, Minimum
-4 F
Operating Temperature, Minimum
-20 C
Size
M32
Standard
cULus, RoHS, WEEE, LVD
Type
Quick Connect Cable Gland
Package Dimensions (L x W x H)
7.09 IN x 3.54 IN x 3.54 IN
Package Dimensions (L x W x H)
18.0086 cm x 8.9916 cm x 8.9916 cm
Package Weight (Imperial)
0.0100 L
Package Weight (Metric)
0.0050 kg
Non Armoured Cable Gland, Thread Size M32, Cable Range 15 to 21mm, Thread Length 15mm, Nylon, Black

NCG-M322B-L

Non Armoured Cable Gland, Thread Size M32, Cable Range 15 to 21mm, Thread Length 15mm, Nylon, Black
Dome Cap Spiral-Flex Cable Gland, black, Polyamide, PG09, cable range .15 - .32

RF09AA-BK

Dome Cap Spiral-Flex Cable Gland, black, Polyamide, PG09, cable range .15 - .32
M50, Sealing Gland for 27-35mm Cable

SG-M50-CBK

M50, Sealing Gland for 27-35mm Cable
Cable gland (IP 68 ? 5 bar), M12x1,5, for cable 3?6 mm

GPA M12

Cable gland (IP 68 ? 5 bar), M12x1,5, for cable 3?6 mm
EP-SG-PG29-LGR-B

1SNG601220R0000

EP-SG-PG29-LGR-B
POLYAMIDE LOCKNUT FOR CABLE GLAND ATEX DIAMETER 40

32403040

POLYAMIDE LOCKNUT FOR CABLE GLAND ATEX DIAMETER 40
Quick Connect Cable Gland, Thread Size M20, Cable Range 7 to 13mm, Thread Length 9mm, Nylon, Light Grey

NPG-M202LG

Quick Connect Cable Gland, Thread Size M20, Cable Range 7 to 13mm, Thread Length 9mm, Nylon, Light Grey
Quick Connect Cable Gland, Thread Size M20, Cable Range 7 to 13mm, Thread Length 9mm, Nylon, Black

NPG-M202B

Quick Connect Cable Gland, Thread Size M20, Cable Range 7 to 13mm, Thread Length 9mm, Nylon, Black

Frequently Asked Questions

What certifications does the NPG-M321B cable gland hold?

The NPG-M321B conforms to UL514B / CSA C22.2 No 18.3 and EN 62444, and is cURus certified.

What is the maximum wall thickness for installation?

The cable gland can be installed in enclosures with a wall thickness ranging from 0.5 mm to 4.0 mm (0.020 to 0.157 inches).

What colors are available for the NPG-M321B cable gland?

The NPG-M321B is available in Black (B), Grey (G), and Light Grey (LG), indicated by the 'x' in the part number.

What is the required hole size for installing the NPG-M321B?

The required hole size for the NPG-M321B is between 32.2 mm and 32.4 mm (1.268 and 1.276 inches).

What is the cable range for the NPG-M321B cable gland?

The NPG-M321B cable gland is suitable for cables with a diameter range of 15.0 to 21.0 mm (0.591 to 0.827 inches).

What certifications does the NPG-M321B cable gland hold?

The NPG-M321B conforms to UL514B / CSA C22.2 No 18.3 and EN 62444, and is cURus certified.

What is the cable range for the NPG-M321B cable gland?

The NPG-M321B cable gland is suitable for cables with a diameter range of 15.0 to 21.0 mm (0.591 to 0.827 inches).

What is the maximum wall thickness for installation?

The cable gland can be installed in enclosures with a wall thickness ranging from 0.5 mm to 4.0 mm (0.020 to 0.157 inches).

What colors are available for the NPG-M321B cable gland?

The NPG-M321B is available in Black (B), Grey (G), and Light Grey (LG), indicated by the 'x' in the part number.

What is the required hole size for installing the NPG-M321B?

The required hole size for the NPG-M321B is between 32.2 mm and 32.4 mm (1.268 and 1.276 inches).
