ABB - Installation Products NPG-0751B - Quick Connect Cable Gland, Thread Size 3/4 Inch NPT, Cable Range 13 to 18mm, Thread Length 9mm, Nylon, Black

ABB Installation Products NPG-0751B Quick Connect Cable Gland, Thread Size 3/4 Inch NPT, Cable Range 13 to 18mm, Thread…

UPC: 786210138480


Documents & Media
Installation InstructionsSpecification SheetManufacturer Product Website

Contact for Pricing

Minimum Qty: 10

Multiplier: 10

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB NPG-0751B Quick-Connect Cable Gland offers a single-piece, tool-free installation solution for industrial electrical enclosures. Constructed from halogen-free nylon (PA6), this gland provides excellent corrosion resistance and durability. It is designed for non-armoured, portable, and tray cables with a diameter range of 13mm to 18mm. The 3/4 Inch NPT thread size ensures compatibility with standard fittings, featuring a 9mm thread length for secure engagement. Key features include: * **Fast Installation:** The Quick-Connect design eliminates the need for locknuts and internal enclosure access, significantly reducing installation time. * **Environmental Protection:** Rated IP66 and IP68 (5 bar for 30 minutes), it offers robust protection against dust and water ingress, suitable for various indoor and protected outdoor environments. * **Temperature Range:** Operates normally from -20°C to +100°C (-4°F to 212°F), with short-term exposure tolerance up to +150°C (-22°F to +302°F). * **Material:** Halogen-free nylon (PA6) construction with chloroprene seals ensures chemical resistance and longevity. Available in black, grey, and light grey. Ideal for panel builders and volume installers, the NPG-0751B is suitable for general-purpose use in control panels, junction boxes, and machinery enclosures where rapid deployment and reliable cable management are essential. The low internal profile and single-piece design simplify assembly while providing effective strain relief.
  • Single-piece, quick-connect design for fast, tool-free installation
  • 3/4 Inch NPT thread size with 9mm thread length
  • Suitable for cable diameters from 13mm to 18mm
  • Halogen-free nylon (PA6) construction with chloroprene seals
  • IP66 and IP68 (5 bar 30 mins) ingress protection ratings

Specifications

Application
General purpose, Ideal for Panel building and Volume Installers
Color
Black
Conductor Range
13 to 18 Millimeters
Connection Type
Quick Connect
Material
Nylon
Material Quality
Nylon
Operating Temperature, Maximum
212 F
Operating Temperature, Maximum
100 C
Operating Temperature, Minimum
-4 F
Operating Temperature, Minimum
-20 C
Series
NPG
Size
3/4 Inch NPT
Size
Thread Size 3/4 Inch NPT, Cable Range 13 to 18mm
Standard
cULus, RoHS, WEEE, LVD
Type
Quick Connect Cable Gland
Package Dimensions (L x W x H)
7.09 IN x 3.54 IN x 3.54 IN
Package Dimensions (L x W x H)
18.0086 cm x 8.9916 cm x 8.9916 cm
Package Weight (Imperial)
0.0100 L
Package Weight (Metric)
0.0050 kg
Single Compresion Cable Gland, M25 Metric Thread, Increased Safety Ex e and Intrinsic Safety Ex i, Cable Range 13 to 18mm, Thread Length 15mm, Nylon, Black

EXCGM25SL

Single Compresion Cable Gland, M25 Metric Thread, Increased Safety Ex e and Intrinsic Safety Ex i, Cable Range 13 to 18mm, Thread Length 15mm, Nylon, Black
Dome Cap Spiral-Flex Cable Gland, black, Polyamide, PG09, cable range .15 - .32

RF09AA-BK

Dome Cap Spiral-Flex Cable Gland, black, Polyamide, PG09, cable range .15 - .32
M50, Sealing Gland for 27-35mm Cable

SG-M50-CBK

M50, Sealing Gland for 27-35mm Cable
Cable gland (IP 68 ? 5 bar), M12x1,5, for cable 3?6 mm

GPA M12

Cable gland (IP 68 ? 5 bar), M12x1,5, for cable 3?6 mm
EP-SG-PG29-LGR-B

1SNG601220R0000

EP-SG-PG29-LGR-B
POLYAMIDE LOCKNUT FOR CABLE GLAND ATEX DIAMETER 40

32403040

POLYAMIDE LOCKNUT FOR CABLE GLAND ATEX DIAMETER 40
Quick Connect Cable Gland, Thread Size 3/4 Inch NPT, Cable Range 11 to 17mm, Thread Length 9mm, Nylon, Light Grey

NPG-0751LG

Quick Connect Cable Gland, Thread Size 3/4 Inch NPT, Cable Range 11 to 17mm, Thread Length 9mm, Nylon, Light Grey
Quick Connect Cable Gland, Thread Size 3/4 Inch NPT, Cable Range 13 to 18mm, Thread Length 9mm, Nylon, Grey

NPG-0751G

Quick Connect Cable Gland, Thread Size 3/4 Inch NPT, Cable Range 13 to 18mm, Thread Length 9mm, Nylon, Grey

Frequently Asked Questions

What are the key features of the NPG Quick-Connect cable gland?

It is a single-piece, corrosion-resistant cable gland designed for fast and simple installation without a locknut, featuring a low internal profile.

What is the cable range for the NPG-0751x model?

The NPG-0751x model accommodates a cable range from 13.0 mm (0.512 in) to 18.0 mm (0.709 in).

How can an NPG cable gland be removed from an enclosure?

A removal tool, sold separately, can be used to push the cable gland from inside the enclosure for easy removal.

Are there different color options for the NPG cable glands?

Yes, NPG cable glands are available in Black, Grey, and Light Grey. The color is specified by replacing the 'x' in the part number.

What is the maximum wall thickness for installation?

The NPG Quick-Connect cable gland can be installed in wall thicknesses from 0.5 mm (0.020 in) to 4.0 mm (0.157 in).

What hole size is required for installing the NPG-0751x?

The required hole size for the NPG-0751x ranges from 27.78 mm (1.094 in) to 28.98 mm (1.141 in).

What certifications does the NPG cable gland conform to?

It conforms to UL514B/CSA C22.2 No 18.3, EN 62444, RoHS, WEEE, and LVD directives.

What is the ingress protection rating of the NPG cable gland?

The NPG cable gland has an ingress protection rating of IP66 and IP68 (5 bar for 30 minutes).

What is the normal operating temperature range for the NPG cable gland?

The normal operating temperature range for the NPG cable gland is -20°C to +100°C (-4°F to 212°F).

What material is the NPG cable gland made from?

The cable gland is constructed from halogen-free nylon (PA6) with chloroprene seals. It is available in Black, Grey, and Light Grey.
