Contact for Pricing
Overview
- 4-conductor control cable for signal and auxiliary functions
- 12-foot length for flexible installation in switchgear
- Male/female molded plugs for quick, secure connections
- Compatible with ABB molded vacuum interrupter systems
- Reduces installation time by eliminating field wiring
Specifications
Type | Control Cable |
Package Dimensions (L x W x H) | 0.01 IN x 0.01 IN x 0.01 IN |
Package Dimensions (L x W x H) | 0.0254 cm x 0.0254 cm x 0.0254 cm |
Package Weight (Imperial) | 1.0000 L |
Package Weight (Metric) | 0.4540 kg |
2-350T
2 Port Aluminum Lug 350 MCM - 6 AWG Aluminum Double Lugs are versatile and reuseable set screw connectors made of 6061T-6 aluminum alloy. Tin plated for low contact resistance. Suitable for use with both copper and aluminum conductors. Rated 600 volts.
2-350TP
Dual Rated Turn Prevent Lug with (2) 350 MCM - 6 AWG conductors is made of 6061T-6 aluminum alloy. Electro-tin plated for low contact resistance. For use with both copper and aluminum conductors. Rated 600V (2000V max. per UL486B). UL 486A/B Listed. Temperature Rating 90 degrees C.
2-350T2
2 Port Aluminum Dual Rated Transformer Lug 350 MCM - 6 AWG - 2 Mounting Holes Aluminum Dual Rated Transformer Lugs are versatile and reuseable set screw connectors made of 6061T-6 aluminum alloy for superior electrical and mechanical performance. Two set screws per wire hole ensure an exceptional connection. Electro-tin plated for low resistance. For use with copper or aluminum conductors. Mounting hole spacing is NEMA 1-3/4". Meets or exceeds ANSI C119.4 Class A. Rated 600 Volts. Temperature Rating 90 degrees C.
100003B
Platinum's RJ45 8-pin/8-position registered jack connector used to connect computers onto Cat5/5e data networks and is recommended for data applications rated to 1 Gb. It simplifies twisted pair terminations by allowing the wires to be inserted through the connector and out the front. This allows the technician to easily verify the proper wiring order. Electrical performance of the termination is optimized by pulling the connector down over the cable jacket and seating it tightly in the rear of the connector. By reducing the distance between the wire twists and contacts, performance is optimized!
100003C
The revolutionary design of the EZ Connectors transformed the way modular plugs are prepped and crimped. By allowing each individual conductor to completely pass through the connector and out of the front greatly simplifies terminations. Installers can easily see and verify the proper wiring order before crimping. The unique design also optimizes electrical performance by reducing the distance between the wire twists and contacts., 899740000384
100010B
Platinum's RJ45 8-pin/8-position registered jack connector used to connect computers onto Cat6 data networks and is recommended for data applicationsrated to 1 Gb. It simplifies twisted pair terminations by allowing the wires to be inserted through the connector and out the front. This allows the technician to easily verify the proper wiring order. Electrical performance of the termination is optimized by pulling the connector down over the cable jacket and seating it tightly in the rear of the connector. By reducing the distance between the wire twists and contacts, performance is optimized!Frequently Asked Questions
What is the length of the MVIEXC12PU cable?
The cable is 12 feet long, providing flexibility in panel layouts.
What is the conductor configuration of this cable?
The cable has 4 conductors for control, monitoring, and auxiliary functions.
Is this cable compatible with ABB vacuum interrupters?
Yes, it is designed for use with ABB molded vacuum interrupter systems.
What type of connectors are included?
The cable features male and female molded plugs for secure connections.
Can this cable be used for signal transmission?
Yes, the 4-conductor configuration supports control and monitoring signals.
