ABB - Installation Products LT75P-QC-LG - Bullet Quick Connect Liquidtight Fitting, 3/4 Inch, Straight, Thermoplastic with Friction Washer, Temperature Rating -2 to +221 F, Light Gray
More images

ABB Installation Products LT75P-QC-LG Bullet Quick Connect Liquidtight Fitting, 3/4 Inch, Straight, Thermoplastic with…

UPC: 786210219165


Documents & Media
Installation InstructionsSpecification SheetManufacturer Product Website

Contact for Pricing

Minimum Qty: 10

Multiplier: 10

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB LT75P-QC-LG Bullet Quick Connect Liquidtight Fitting is a 3/4" straight thermoplastic fitting designed for secure, tool-free cable connections in industrial environments. Constructed from durable light gray thermoplastic (RAL 7035), this fitting provides reliable protection against moisture, dust, and mechanical stress while maintaining a temperature rating from -2°F to +221°F (-19°C to +105°C). The quick-connect design eliminates the need for traditional threading or clamps, reducing installation time by up to 50% compared to conventional fittings. The integrated friction washer ensures a tight seal, preventing liquid ingress and maintaining cable integrity in harsh conditions. Key features include a single-piece construction with no locknut required, allowing for quick and easy installation without access to the inside of the enclosure. The swivel mechanism enables fast conduit installation, and assemblies can be connected to conduit without disassembly. The rugged, low-profile non-metallic body and gland construction provide corrosion resistance and double sealing action. The elongated gland nut profile offers additional strain relief for 90° pull and an easy hand grip. The connector ferrule accommodates variations in conduit inside diameter and tolerates field-cut conduit. This fitting is ideal for applications in manufacturing plants, food processing facilities, wastewater treatment, and outdoor installations where environmental protection is critical. Its performance remains unaffected by exposure to detergents, cleaners, sanitizers, and cutting fluids commonly encountered in industrial environments. The LT-QC series from ABB Installation Products is trusted for consistent performance in demanding settings, making it a cost-effective solution for both new installations and retrofits.
  • 3/4" straight thermoplastic fitting with light gray (RAL 7035) finish
  • Temperature rating: -2°F to +221°F (-19°C to +105°C)
  • Tool-free quick-connect design reduces installation time by up to 50%
  • Single-piece construction with no locknut required for easy installation
  • Corrosion-resistant, double sealing action for moisture and dust protection

Specifications

Application
Ideal for panel builders and volume installers
Color
Light Gray
Color
Gray
Connection Type
Quick-Connect
Material
Thermoplastic
Material
Weather stabilized thermoplastic
Series
LT-QC
Size
3/4 in
Size
3/4 Inch
Standard
ANSI/UL514B , CSA 22.2 No. 18.3-12
Type
Bullet Quick Connect Fitting
Package Dimensions (L x W x H)
7 IN x 3.5 IN x 3.5 IN
Package Dimensions (L x W x H)
17.78 cm x 8.89 cm x 8.89 cm
Package Weight (Imperial)
0.0700 L
Package Weight (Metric)
0.0320 kg
Liquidtight Connector, Straight, 1/2 Inch, Plastic, Gray

LT 501

Liquidtight Connector, Straight, 1/2 Inch, Plastic, Gray
3/4" nonmetallic screw-on 90 degree connector

471-NMLTS

3/4" nonmetallic screw-on 90 degree connector
Bullet Quick Connect Liquidtight Fitting, 1 Inch, Straight, Thermoplastic with Friction Washer, Temperature Rating -2 to +221 F, Light Gray

LT100P-QC-LG

Bullet Quick Connect Liquidtight Fitting, 1 Inch, Straight, Thermoplastic with Friction Washer, Temperature Rating -2 to +221 F, Light Gray
High Temperature Liguid-tight Straight Fitting, Trade Size 1/2 Inch, M20 Thread, 316 Stainless Steel with Zinc Plated Steel Ground Cone

9332SST6HT

High Temperature Liguid-tight Straight Fitting, Trade Size 1/2 Inch, M20 Thread, 316 Stainless Steel with Zinc Plated Steel Ground Cone
High Temperature Liguid-tight Straight Fitting, Trade Size 3/8 Inch, M16 Thread, 316 Stainless Steel with Zinc Plated Steel Ground Cone

9330SST6HT

High Temperature Liguid-tight Straight Fitting, Trade Size 3/8 Inch, M16 Thread, 316 Stainless Steel with Zinc Plated Steel Ground Cone
Liguid-tight Straight Fitting, Trade Size 3/8 Inch, M16 Thread, 316 Stainless Steel Body and Ground Cone

9330SST6-6

Liguid-tight Straight Fitting, Trade Size 3/8 Inch, M16 Thread, 316 Stainless Steel Body and Ground Cone
Liguid-tight Straight Fitting, Trade Size 1/2 Inch, M20 Thread, 316 Stainless Steel Body and Ground Cone

9332SST6-6

Liguid-tight Straight Fitting, Trade Size 1/2 Inch, M20 Thread, 316 Stainless Steel Body and Ground Cone
High Temperature Liguid-tight 45 Degree Fitting, Trade Size 1-1/2 Inch, M50 Thread, 316 Stainless Steel with Zinc Plated Steel Ground Cone

9346SST6HT

High Temperature Liguid-tight 45 Degree Fitting, Trade Size 1-1/2 Inch, M50 Thread, 316 Stainless Steel with Zinc Plated Steel Ground Cone

Frequently Asked Questions

What material is the fitting made from?

The fitting is made from light gray thermoplastic, providing durability and chemical resistance.

Does this fitting require tools for installation?

No, the quick-connect design allows for tool-free installation.

Is this fitting compatible with liquidtight conduit?

Yes, the LT75P-QC-LG is designed for use with liquidtight conduit systems.

How to Install the BULLET Quick-Connect Liquidtight Fitting (LT75P-QC-LG)

This guide provides step-by-step instructions for installing the BULLET Quick-Connect liquidtight fitting, ensuring a secure and proper connection for electrical conduits. WARNING: Risk of shock, disconnect power before installation.

Estimated time: 15m

Tools needed:

Wrench, Conduit cutting tool

Supplies needed:

Electrical conduit, BULLET Quick-Connect liquidtight fitting (LT75P-QC-LG), Electrical enclosure

  1. Prepare the Conduit and Disconnect Power

    Ensure power is off before proceeding. Cut the conduit clean and square, preparing it for insertion into the fitting. This product should be installed by a qualified electrician in accordance with national and local electrical codes.

  2. Connect Conduit to Fitting

    Insert the prepared conduit through the gland-nut opening. Push the conduit firmly to the bottom of the fitting with a slight twisting motion to ensure a secure connection.

  3. Secure the Gland-Nut

    Tighten the gland-nut by hand until snug, then use a wrench to fully tighten it down to the body shoulder of the fitting. Ensure it is firmly secured to create a liquidtight seal.

  4. Mount Fitting to Enclosure

    Insert the assembled fitting into the clearance or threaded hole of the electrical enclosure. Ensure proper alignment.

  5. Tighten Fitting to Enclosure

    Tighten the body of the fitting securely to the enclosure. Verify that the fitting is firmly attached and sealed against the enclosure.
