Contact for Pricing
Overview
- 3 inch copper-free aluminum die-cast body for corrosion resistance
- Tin-plated aluminum lay-in-lug for secure grounding connections
- Electro-zinc plated steel screw for durability
- Designed for data and control applications sensitive to floating voltage
- Mitigates voltage differences in microprocessor and instrumentation systems
Specifications
Application | Extreme Grounding for Data and Control Applications |
Color | Silver |
Connection Type | Lay-in Lug |
Material | Aluminum, Steel, Zinc |
Material of Construction | Copper free aluminum die cast |
Size | 3 Inch |
Size | 3 Inches |
Standard | UL E3060, CSA 4484 |
Type | Locknuts |
Package Dimensions (L x W x H) | 0.01 IN x 0.01 IN x 0.01 IN |
Package Dimensions (L x W x H) | 0.0254 cm x 0.0254 cm x 0.0254 cm |
Package Weight (Imperial) | 0.3000 L |
Package Weight (Metric) | 0.1360 kg |
L200GRL
2 inch copper free aluminum die cast grounding locknut with tin plated aluminum lay-in-lug and electro zinc plated steel screw.L350GRL
3-1/2 inch copper free aluminum die cast grounding locknut with tin plated aluminum lay-in-lug and electro zinc plated steel screw.L125GRL
1-1/4 inch copper free aluminum die cast grounding locknut with tin plated aluminum lay-in-lug and electro zinc plated steel screw.
L150GRL
1-1/2 inch copper free aluminum die cast grounding locknut with tin plated aluminum lay-in-lug and electro zinc plated steel screw.L400GRL
4 inch copper free aluminum die cast grounding locknut with tin plated aluminum lay-in-lug and electro zinc plated steel screw.L075GRL
3/4 inch copper free aluminum die cast grounding locknut with tin plated aluminum lay-in-lug and electro zinc plated steel screw.L100GRL
1 inch copper free aluminum die cast grounding locknut with tin plated aluminum lay-in-lug and electro zinc plated steel screw.
L050GRL
1/2 inch copper free aluminum die cast grounding locknut with tin plated aluminum lay-in-lug and electro zinc plated steel screw.
GMM-M12
Hexagonal Lock Nut with Metric Threads, Material - Nickel-Plated Brass, Thread Size - M12x1.5Frequently Asked Questions
What material is the ABB L300GRL grounding locknut made from?
The ABB L300GRL features a copper-free aluminum die-cast body, a tin-plated aluminum lay-in-lug, and an electro-zinc plated steel screw.
What is the primary application for the L300GRL grounding locknut?
The L300GRL is designed for data and control applications sensitive to floating voltage differences, particularly in environments with microprocessors and instrumentation.
What is the size of the ABB L300GRL grounding locknut?
The ABB L300GRL grounding locknut is 3 inches in size.
What type of lug is included with the L300GRL grounding locknut?
The L300GRL includes a tin-plated aluminum lay-in-lug.
What type of screw is used on the L300GRL grounding locknut?
The L300GRL grounding locknut uses an electro-zinc plated steel screw.
