ABB - Installation Products L 600-58 - Tin Plated Copper One-Hole Straight NEMA Lugs. wire size 600 kcmil CU. Installing Dies 96, 1 1-8/1. Length 5-1/8 inch. Pad 1-23/32 inch wide x 1-3/4 inch long x 1/4 inch thick. (1) 11/16 inch hole. Barrel 2-39/64 inch. CSA. UL listed.

ABB Installation Products L 600-58 Tin Plated Copper One-Hole Straight NEMA Lugs. wire size 600 kcmil CU. Installing Dies…

UPC: 783786739387


Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 100

Multiplier: 100

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB L 600-58 is a tin-plated copper one-hole straight NEMA lug designed for robust electrical connections. This lug is engineered to accommodate a wire size of 600 kcmil copper (CU), ensuring high conductivity and reliable performance in demanding applications. It features a single 11/16 inch hole for secure mounting. The lug boasts a substantial barrel length of 2-39/64 inches, providing ample surface area for conductor termination and minimizing resistance. Its pad dimensions are 1-23/32 inches wide by 1-3/4 inches long, with a thickness of 1/4 inch, offering a solid foundation for connections. Installation is facilitated by the requirement for installing dies 96 and 1 1-8/1. With an overall length of 5-1/8 inches, this lug provides sufficient space for wiring and management. The ABB L 600-58 is both CSA and UL listed, signifying its adherence to stringent safety and performance standards. This product is ideal for industrial power distribution, heavy-duty equipment connections, and any application requiring a dependable termination for large gauge copper conductors. Trust ABB Installation Products for quality and reliability in your electrical infrastructure.
  • Tin Plated Copper for corrosion resistance and conductivity
  • Accommodates 600 kcmil copper (CU) wire size
  • Single 11/16 inch mounting hole
  • CSA and UL listed for safety and reliability
  • Durable construction with 1/4 inch thick pad

Specifications

Connection
Compression
Connection Type
One-Hole Straight
Finish
Tin Plated
Housing Material
Copper
Insulation
None
Material
Tin Plated Copper
Size
Length 5-1/8 in
Size
600 kcmil CU
Standard
CSA, UL Listed
Type
Compression Lug One Hole
Wire Size
CU 600 kcmil
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
0.7000 L
Package Weight (Metric)
0.3180 kg
Heat Shrink Ring Terminal 12 10 AWG, 3/8" stud size.

PH10-38R-E

Heat Shrink Ring Terminal 12 10 AWG, 3/8" stud size.
Service Post Connector - Two Wire Type 4 STR Service Post Connectors is used for connecting one or two conductors. Made from high copper content hard-drawn rod. Lay-in feature makes them excellent for continuous loop grounding and bonding. Used to ground to bar or plate. Suitable for direct burial in earth or concrete.

SPM-24L

Service Post Connector - Two Wire Type 4 STR Service Post Connectors is used for connecting one or two conductors. Made from high copper content hard-drawn rod. Lay-in feature makes them excellent for continuous loop grounding and bonding. Used to ground to bar or plate. Suitable for direct burial in earth or concrete.
Copper C-Tap, 600V, Wire Range-Main: 6-8, Branch 8-12, Length 9/16 Inch, Height 5/8 Inch, Tin Plated, Die Color Code Gray, Die Code 29

54715TPTC

Copper C-Tap, 600V, Wire Range-Main: 6-8, Branch 8-12, Length 9/16 Inch, Height 5/8 Inch, Tin Plated, Die Color Code Gray, Die Code 29
Long Barrel Two-Way Copper Connector, Cable Size 350 kcmil, Navy 350 (91), Length 4-1/8 Inches, Diameter 15/16 Inch, Die Color Red, Die Code 71 or 71H, Silver Plated

271-30630-12

Long Barrel Two-Way Copper Connector, Cable Size 350 kcmil, Navy 350 (91), Length 4-1/8 Inches, Diameter 15/16 Inch, Die Color Red, Die Code 71 or 71H, Silver Plated
Omni-Plus Insert Jack - Black. Omno-Plus.

OPPJINBK

Omni-Plus Insert Jack - Black. Omno-Plus.
Keystone Insert, F-Connector, 1GHz, White, Recessed, Female to Female

OPAF-WH

Keystone Insert, F-Connector, 1GHz, White, Recessed, Female to Female
Cast Copper Lug for 775/24 DLO conductor with a 5/16 Inch Bolt Hole

251-30485-945

Cast Copper Lug for 775/24 DLO conductor with a 5/16 Inch Bolt Hole
E-Z-Ground Figure 8 Copper Compression Ground Rod Tap Connector for Cable Range 4/0 AWG - 250 kcmil, Ground Rod 3/4, Tin-Plated

GR34-40250TP

E-Z-Ground Figure 8 Copper Compression Ground Rod Tap Connector for Cable Range 4/0 AWG - 250 kcmil, Ground Rod 3/4, Tin-Plated

Frequently Asked Questions

What wire size does the ABB L 600-58 lug accommodate?

The ABB L 600-58 lug is designed to accommodate a wire size of 600 kcmil copper (CU).

What are the dimensions of the pad on the L 600-58 lug?

The pad on the L 600-58 lug measures 1-23/32 inches wide by 1-3/4 inches long and is 1/4 inch thick.

What is the hole size for mounting the L 600-58 lug?

The L 600-58 lug features a single 11/16 inch hole for mounting.

Is the ABB L 600-58 lug CSA and UL listed?

Yes, the ABB L 600-58 lug is both CSA and UL listed, ensuring it meets industry safety standards.

What are the required installing dies for the L 600-58 lug?

The required installing dies for the L 600-58 lug are 96 and 1 1-8/1.
