ABB - Installation Products KV18-250FD-M - Vinyl 250 Female Disconnect Wire Range 22-16, Red, 1000 pack

ABB Installation Products KV18-250FD-M Vinyl 250 Female Disconnect Wire Range 22-16, Red, 1000 pack

UPC: 786210107127


Documents & Media
Specification SheetManufacturer Product Website

Contact for Pricing

Minimum Qty: 1000

Multiplier: 1000

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

This offering consists of 1000 units of the ABB Vinyl 250 Female Disconnect, SKU KV18-250FD-M. These disconnect terminals are designed for wire ranges of 22 to 16 AWG. The color designation for this specific model is red, which typically indicates a voltage rating suitable for lower voltage applications within this wire gauge range. The vinyl insulation provides electrical isolation and mechanical protection for the connection point. These connectors are suitable for terminating wires in electrical circuits where a disconnectable connection is required. The female configuration allows for mating with a male spade terminal or connector. The UNSPSC code 39121447 categorizes these as electrical connectors. ABB is a recognized manufacturer in the installation products sector, known for providing reliable electrical components. This bulk 1000-pack quantity is suitable for projects requiring a significant number of these disconnect terminals, ensuring availability for production lines or extensive electrical installations. The vinyl construction offers a balance of insulation properties and cost-effectiveness for general-purpose electrical connections.
  • Manufacturer: ABB - Installation Products
  • SKU: KV18-250FD-M
  • Type: Vinyl 250 Female Disconnect
  • Wire Range: 22-16 AWG
  • Color: Red
  • Quantity: 1000 pack

Specifications

Color
Red
Finish
Tin Plated
Insulation
Yes
Standard
UL E66716
Type
Vinyl Insulated Female Disconnect
Wire Size
22-18 AWG
Package Dimensions (L x W x H)
7 IN x 5 IN x 3.25 IN
Package Dimensions (L x W x H)
17.78 cm x 12.7 cm x 8.255 cm
Package Weight (Imperial)
0.0010 L
Package Weight (Metric)
0.0010 kg
