ABB - Installation Products KNF18-250MD-D - Fully Insulated Nylon Male - 250 Series Disconnects for Wire Range 22-16 , Tab Size .250x.032, Red

ABB Installation Products KNF18-250MD-D Fully Insulated Nylon Male - 250 Series Disconnects for Wire Range 22-16 , Tab Size…

UPC: 786210108018


Documents & Media
Specification SheetManufacturer Product Website

Contact for Pricing

Minimum Qty: 500

Multiplier: 500

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB KNF18-250MD-D is a fully insulated nylon male disconnect terminal designed for secure electrical connections in industrial and commercial applications. This 250 Series terminal accommodates wire ranges from 22 to 16 AWG (0.5-1.5 mm²) with a standard .250 x .032 inch tab size, ensuring compatibility with a wide range of mating female disconnects. The red color coding provides quick visual identification of the wire gauge range, reducing installation errors and improving safety. Constructed from brass with a copper sleeve, the terminal delivers reliable conductivity and mechanical strength. The fully insulated nylon housing prevents accidental contact with live conductors, minimizing the risk of short circuits and electrical shock. With a maximum electrical rating of 105°C and 300 volts, this disconnect is ideal for use in control panels, machinery, and other electrical systems requiring secure, insulated connections. The funnel entry design and internal barrel serrations facilitate easy wire insertion and retention, while the molded insulator ensures long-term durability. Compatible with tools ERG2500 and KT2500, the KNF18-250MD-D is a dependable choice for professional electrical installations.
  • Fully insulated nylon housing for safety and durability
  • Accommodates 22-16 AWG (0.5-1.5 mm²) wire range
  • Standard .250 x .032 inch tab size for compatibility
  • Maximum electrical rating: 105°C, 300 volts
  • Red color coding for easy wire gauge identification

Specifications

Color
Red
Connection Type
Disconnect Terminal
Insulation
Yes
Material
Nylon
Material
Brass
Series
250 Series
Special Features
Fully Insulated. Metal Insulation Sleeve. Molded Insulator. Internal Barrel Serrations. Funnel Entry
Standard
UL E66716
Type
Nylon Fully Insulated Male Disconnect
Package Dimensions (L x W x H)
7 IN x 5 IN x 3.25 IN
Package Dimensions (L x W x H)
17.78 cm x 12.7 cm x 8.255 cm
Package Weight (Imperial)
0.0010 L
Package Weight (Metric)
0.0010 kg
Nylon Insulated Wristlock Disconnect, Length 1.70 Inches, Single Piece Length .99 Inches, Maximum Insulation .136, Wire Range #22-#18 AWG, Color Red, Copper, Tin Plated, 1,000 Pack

RA23

Nylon Insulated Wristlock Disconnect, Length 1.70 Inches, Single Piece Length .99 Inches, Maximum Insulation .136, Wire Range #22-#18 AWG, Color Red, Copper, Tin Plated, 1,000 Pack
16-14 AWG Uninsulated Female Flag Terminal with 0.250 Stud - 20 Count Uninsulated Female Disconnects is made of electro tin plated copper. 600V, 105 degrees C. FEATURES: STYLE: Female Flag MATERIAL: Tin Plated Brass QUANTITY: 20 Count WIRE SIZE: 16-14 STUD SIZE: 0.250 BRAND EQUIVALENT: Morris Products 12424 Ideal 83-9401

SF16-250-3-S

16-14 AWG Uninsulated Female Flag Terminal with 0.250 Stud - 20 Count Uninsulated Female Disconnects is made of electro tin plated copper. 600V, 105 degrees C. FEATURES: STYLE: Female Flag MATERIAL: Tin Plated Brass QUANTITY: 20 Count WIRE SIZE: 16-14 STUD SIZE: 0.250 BRAND EQUIVALENT: Morris Products 12424 Ideal 83-9401
Insulated Nylon Female Barrel Flag Disconnects for Wire Range 16-14 , Tab Size .250x.032, Blue

KNF14-250BFD-D

Insulated Nylon Female Barrel Flag Disconnects for Wire Range 16-14 , Tab Size .250x.032, Blue
Insulated Nylon Female Barrel Flag Disconnects for Wire Range 22-18 , Tab Size .250x.032, Red

KNF18-250BFD-D

Insulated Nylon Female Barrel Flag Disconnects for Wire Range 22-18 , Tab Size .250x.032, Red
Insulated Nylon Female Barrel Flag Disconnects for Wire Range 12-10 , Tab Size .250x.032, Yellow

KNF10-250BFD-D

Insulated Nylon Female Barrel Flag Disconnects for Wire Range 12-10 , Tab Size .250x.032, Yellow
Nylon - Fully Enclosed 250 Flag Disconnect Wire Range 12-10 Bolt Hole n/a

KNF10-250BFD-T

Nylon - Fully Enclosed 250 Flag Disconnect Wire Range 12-10 Bolt Hole n/a
Nylon Fully Insulated 110 Disconnect (x.020) Wire Range 22-16 Bolt Hole n/a, Mylar Tape Red

KNF18-110-20FD-T

Nylon Fully Insulated 110 Disconnect (x.020) Wire Range 22-16 Bolt Hole n/a, Mylar Tape Red
Male Tab Coupler Disconnect Bolt Hole #6 Tab Size .250 x .032

TA251

Male Tab Coupler Disconnect Bolt Hole #6 Tab Size .250 x .032

Frequently Asked Questions

What wire gauge range does this disconnect support?

The KNF18-250MD-D supports wire ranges from 22 to 16 AWG (0.5-1.5 mm²).

What is the maximum operating temperature?

The maximum operating temperature for this disconnect is 105°C.

What is the tab size of this disconnect?

The tab size is .250 x .032 inches.

What color is the KNF18-250MD-D disconnect?

The KNF18-250MD-D is colored red.

What tools are compatible with this disconnect?

Compatible tools include ERG2500 and KT2500.

What is the maximum voltage rating?

The maximum voltage rating is 300 volts.

What is the terminal material?

The terminal is made of brass with a copper sleeve.
