ABB Installation Products FST 125 Aluminum Flood-Seal 125 Series Connectors - Service Entrance Connectors, #12 to 500…
UPC: 783786725304
Documents & Media
Contact for Pricing
Minimum Qty: 20
Multiplier: 20
*Contact for lower quantities*
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- Aluminum construction for corrosion resistance and durability
- Flood-seal design with black EPDM rubber insulation for weatherproofing
- Two-way configuration with three T-type outlets (#12 to 500 kcmil)
- Dimensions: 6.041" W x 3.748" H, includes 3 mounting screws
- Suitable for service entrance, meter sockets, and branch circuits
Specifications
Application | Multi-port Connector |
Color | Black |
Conductor Range | #12 to 500 kcmil |
Connection | Mechanical |
Connection Type | Screw |
Insulation | EPDM Rubber |
Material | Aluminum Connector, PVC Insulation |
Material | Aluminum, EPDM Rubber, Screws |
Number Of Conductors | 3 |
Number of Poles | 3 |
Poles | 3 |
Series | 125 Series |
Size | 6.041 inch wide x 3.748 inch tall |
Size | 6.041 inch x 3.748 inch |
Special Features | All Outlets Approved for Full cable rating - Safe and Reliable. All Connectors are 100 percent Hi-Pot Tested at 4000 Volts for 60 seconds. Designed for Maximum Contact to ensure Cooler Operation and more reliable joints. Outlets equipped with 1/2 inch Hex-head bolts with Captive Belleville washers to accept Standard one or two hole NEMA Aluminum or Copper Lugs |
Standard | ANSI C119.4 |
Type | Flood Seal Multi Port Connector 125 Series |
Package Dimensions (L x W x H) | 0.01 IN x 0.01 IN x 0.01 IN |
Package Dimensions (L x W x H) | 0.0254 cm x 0.0254 cm x 0.0254 cm |
Package Weight (Imperial) | 1.0200 L |
Package Weight (Metric) | 0.4630 kg |
FS 6-125 CSN
Flood Seal, Aluminum Bus Connector, #12 - 500 kcmil, Aluminum and Copper, Bolt 1/2 inch, Six Tower
FS 1212-175 AWR
Aluminum 175 Series Bus Connector, Two-Way Configuration - Outlets 24 - 12 Towers per side, 2-Holes per Tower, Length 35-1/4 inch, Assembled with (24) Insulating Rockets, Includes (48) Screws and Silicone Grease.FS 1010-175 AWR
Aluminum 175 Series Bus Connector, Two-Way Configuration - Outlets 20, Length 23-1/4 inch x 12-1/4 inch Wide, Includes (20) Insulating Rockets, 40 Screws, Silicone Grease, Coated with Black EPDM Rubber.
FS 10-125
Aluminum Flood-Seal 125 Series Connectors - one-way configuration, one-bolt design, length 18-1/2 inch, outlets 10, includes 10 Insulating Towers and 10 Screws.FS 1212-175 CUAWR
Tin-Plated Copper Flood-Seal 175 Series Connectors - Two-Way Configuration, Assembled with Insulating Rockets, Length 35-1/8 inch, Outlets 24 - 12 Towers per Side - 2-Holes per Tower. Includes 48 Screws.
FS 175-12 CU-1500
Flood Seal, Tin Plated Copper Bus Connector with Studs. Row of 12 Outlets. Two holes each Outlet. 36.00 inch x 7.0 inch x 2.250 inch Thick. Includes 24 Screws for Towers and Four 1/2-13 UNC-2B Stainless Steel Studs Assembled with Loctite. Main Body Coated with Black EPDM Rubber.
FS 175-12 CE
Flood Seal, Aluminum Bus Connector, 1/0 - 1000 KCMIL, Aluminum and Copper, Bolt 1/2 inch, Twelve Towers, Includes 12 Insulating Rockets, 24 Stainless Steel Washers, 24 Screws, 12 Spacers, 2 Stainless Steel Studs 1-3/4 inch long and Silicone Grease. Main Body Coated with Black EPDM Rubber.
FS 212-6493
Flood Seal Connector Kit, For Use with 4/0 Secondary Triplex with 2/0 Neutral. Contains Oxide Inhibiting Compound. Tin-Plated Aluminum. Kit Includes Total of 15 Insulating Rockets, (2) Feeder Connectors, (1) Neutral Connector, (18) Stainless Steel Flat Washers, (18) Stainless Steel Flat Washers, (18) Screws, Silicone Grease and Instruction Sheet. Each Connector has 5 Towers - Center Tower has 2-Holes, other Towers have only 1-Hole.Frequently Asked Questions
What conductor sizes are compatible with the FST 125?
The FST 125 supports conductors ranging from #12 AWG to 500 kcmil.
What type of insulation does the FST 125 use?
The FST 125 features black EPDM rubber insulation for weatherproofing and durability.
How many outlets does the FST 125 have?
The FST 125 has three outlets in a T-type configuration.
What are the dimensions of the FST 125?
The FST 125 measures 6.041 inches wide by 3.748 inches tall.
Does the FST 125 include mounting hardware?
Yes, the FST 125 includes three mounting screws for installation.
Is the FST 125 suitable for outdoor use?
Yes, the flood-seal design and EPDM insulation make it suitable for outdoor or damp environments.
What applications is the FST 125 designed for?
The FST 125 is designed for service entrance panels, meter sockets, and branch circuits.
