ABB - Installation Products CU20 - Type CU Copper Splice, Long Barrel, 2-1/8 Inch Length, Max 35kV, Wire Size 2/0 Str, Tin Plated, Die Color Code Black

ABB Installation Products CU20 Type CU Copper Splice, Long Barrel, 2-1/8 Inch Length, Max 35kV, Wire Size 2/0 Str, Tin…

UPC: 783786132201


Documents & Media
Specification SheetVideo ClipManufacturer Product Website

Contact for Pricing

Minimum Qty: 10

Multiplier: 10

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB CU20 is a Type CU long barrel copper splice designed for reliable electrical power connections up to 35kV. Constructed from high-conductivity wrought copper with an electro tin plated finish, this splice ensures excellent conductivity and corrosion resistance. Its long barrel design, measuring 2-1/8 inches, provides substantial conductor overlap for secure and robust terminations. Specifically engineered for 2/0 AWG stranded copper wire, the CU20 offers a precise fit for this common conductor size. The integrated Color-Keyed® identification system, indicated by the black die color code, simplifies tool and die selection for proper installation. The chamfered barrel design facilitates wire insertion and maximizes the crimp area, contributing to a dependable connection. 65-18. It also meets RoHS3 (European Directive 2011/65 and Commission Delegated Directive 2015/863) requirements. Installation is supported by a range of hydraulic and battery-operated tools, including TBM6H, TBM12, TBM15I, 21940, BPLT6BSCR, BPLT62BSCR, BLT14BSCR, and BPLT15BSCR. The ABB CU20 is suitable for critical power distribution applications in utility substations, industrial facilities, and transmission infrastructure where high voltage insulation and dependable current transfer are paramount. SKU: CU20.
  • High-conductivity wrought copper construction with electro tin plating
  • Long barrel design (2-1/8 inch) for maximum conductor overlap
  • Rated for 600V to 35kV applications
  • Designed for 2/0 AWG stranded copper wire
  • Color-Keyed® identification system with black die code for proper tooling

Specifications

Application
For use on aluminum conductors
Color
Black
Connection Type
Splice
Finish
Tin Plated
Insulation
None
Insulation
False
Material
Copper
Material
Copper, Tin Plated
Series
Type CU
Size
2/0 AWG Stranded Copper Wire, 2-1/8 Inch Length
Special Features
Made of high-conductivity seamless copper tubing. Tin plated for corrosion resistance
Standard
UL E9809
Type
Splice Connector
Voltage Rating
35 kV
Package Dimensions (L x W x H)
3.3 IN x 2.8 IN x 2.3 IN
Package Dimensions (L x W x H)
8.382 cm x 7.112 cm x 5.842 cm
Package Weight (Imperial)
0.0700 L
Package Weight (Metric)
0.0320 kg
Copper Two-Way Splice, Standard Barrel, Max 35kV, Wire Size 2/0 AWG, Plain Finish, Die Code 45, Die Color Code Black

54510PF

Copper Two-Way Splice, Standard Barrel, Max 35kV, Wire Size 2/0 AWG, Plain Finish, Die Code 45, Die Color Code Black
StandardBarrel TinnedCopperSplice2/0 AWG Standard Barrel Tinned CopperSplices is a type of copper compression connector that is produced from high conductivity copper tubing. They are tin-plated to provide corrosion resistance and are marked with die index and color coded for easy reference. Listed for 35KV maximum when properly installed.

SC-2/0

StandardBarrel TinnedCopperSplice2/0 AWG Standard Barrel Tinned CopperSplices is a type of copper compression connector that is produced from high conductivity copper tubing. They are tin-plated to provide corrosion resistance and are marked with die index and color coded for easy reference. Listed for 35KV maximum when properly installed.
Copper butt splice, long barrel, 750 kcmil cable.

SCL750-6

Copper butt splice, long barrel, 750 kcmil cable.
Type CU Copper Splice, Long Barrel, 2-3/4 Inch Length, Max 35kV, Wire Size 4/0 Str, Tin Plated, Die Color Code Purple

CU40

Type CU Copper Splice, Long Barrel, 2-3/4 Inch Length, Max 35kV, Wire Size 4/0 Str, Tin Plated, Die Color Code Purple
Type CU Copper Splice, Long Barrel, 3-3/4 Inch Length, Max 35kV, Wire Size 400 kcmil, Tin Plated, Die Color Code Blue

CU400

Type CU Copper Splice, Long Barrel, 3-3/4 Inch Length, Max 35kV, Wire Size 400 kcmil, Tin Plated, Die Color Code Blue
Type CU Copper Splice, Long Barrel, 4-3/4 Inch Length, Max 35kV, Wire Size 500 kcmil, Tin Plated, Die Color Code Brown

CU500

Type CU Copper Splice, Long Barrel, 4-3/4 Inch Length, Max 35kV, Wire Size 500 kcmil, Tin Plated, Die Color Code Brown
Type CU Copper Splice, Long Barrel, 4-1/4 Inch Length, Max 35kV, Wire Size 600 kcmil, Tin Plated, Die Color Code Green

CU600

Type CU Copper Splice, Long Barrel, 4-1/4 Inch Length, Max 35kV, Wire Size 600 kcmil, Tin Plated, Die Color Code Green
Type CU Copper Splice, Long Barrel, 1-3/4 Inch Length, Max 35kV, Wire Size 8 Str, Tin Plated, Die Color Code Red

CU8

Type CU Copper Splice, Long Barrel, 1-3/4 Inch Length, Max 35kV, Wire Size 8 Str, Tin Plated, Die Color Code Red
