ABB - Installation Products CSS 8500 C - Aluminum Transformer Connector-CSS Series, Screw-on Style, Cable Range 2-500, Stud Size 1 Inch, Insulator Length 11-3/16 Inch, Outlets 8, Oxide Inhibitor
ABB - Installation Products

CSS 8500 C

UPC: 783786715619

Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 30

Multiplier: 30

*Contact for lower quantities*

Overview

The ABB CSS 8500 C is a screw-on aluminum transformer connector designed for secure, high-capacity cable connections in industrial electrical systems. This connector supports cable ranges from 2 AWG to 500 MCM, making it suitable for heavy-duty applications where robust current carrying capacity is required. The 1-inch stud size ensures compatibility with standard transformer bushings and distribution equipment, while the 11-3/16-inch insulator length provides adequate clearance for high-voltage installations. With 8 outlets, the CSS 8500 C allows for multiple cable terminations in a single unit, reducing installation time and complexity. The oxide inhibitor included in the design prevents corrosion at connection points, maintaining long-term conductivity and reliability. This connector is part of ABB’s Installation Products line, a trusted brand in electrical infrastructure solutions. Common applications include power distribution transformers, switchgear, and industrial control panels where aluminum conductors are specified. The screw-on style design simplifies installation and maintenance, ensuring a tight, vibration-resistant connection. For environments requiring durable, corrosion-resistant connectors, the ABB CSS 8500 C delivers consistent performance with minimal maintenance.
  • Screw-on aluminum connector for secure cable terminations
  • Supports cable range from 2 AWG to 500 MCM
  • 1-inch stud size for compatibility with standard transformer bushings
  • 11-3/16-inch insulator length for high-voltage clearance
  • Includes oxide inhibitor to prevent corrosion

Specifications

Application
Screw-on Transformer Connector
Conductor Range
#2 to 500 kcmil
Connection
Mechanical
Insulation
PVC Cover
Material
Aluminum
Number of Conductors
8
Size
11-3/16 inch
Special Features
Clear PVC Insulating Boot. Disconnectable - easy to install and remove. Dual-rated to accept Aluminum and Copper Conductors
Standard
ANSI C119.4
Type
Quick-Disconnect Transformer Connector
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
2.2500 L
Package Weight (Metric)
1.0210 kg
Aluminum Flood-Seal Twin-Screw Mechanical Connectors for 500 kcmil series - wire range 2-500 kcmil, length 3-7/8 inch, height 4-3/4 inch, outlets 2 with 2-Holes each. Black PVC Coating.

UH 500-2 R

Aluminum Flood-Seal Twin-Screw Mechanical Connectors for 500 kcmil series - wire range 2-500 kcmil, length 3-7/8 inch, height 4-3/4 inch, outlets 2 with 2-Holes each. Black PVC Coating.
Aluminum Transformer Connector-CSW Series - Quick Disconnect, Cable Range 12-350, Stud Size 5/8 Inch, Insulator Length 5-11/16 Inch, Outlets 4, Oxide Inhibitor And Street Light Outlet Option

CSW 4350 SLC

Aluminum Transformer Connector-CSW Series - Quick Disconnect, Cable Range 12-350, Stud Size 5/8 Inch, Insulator Length 5-11/16 Inch, Outlets 4, Oxide Inhibitor And Street Light Outlet Option
Aluminum Transformer Connector-CSW Series - Quick Disconnect, Cable Range 12-350, Stud Size 1 Inch, Insulator Length 5-11/16 Inch, Outlets 4, Oxide Inhibitor And Street Light Outlet Option

CSW 4350-1 SLC

Aluminum Transformer Connector-CSW Series - Quick Disconnect, Cable Range 12-350, Stud Size 1 Inch, Insulator Length 5-11/16 Inch, Outlets 4, Oxide Inhibitor And Street Light Outlet Option
Copper 175 Series Clamp-On Style Transformer and Network Protection Connectors - vertical cable leads, stud size 3 inch, outlets 8, 9.50 Height, 10.75 tower width

FTT 44-175-30 CU

Copper 175 Series Clamp-On Style Transformer and Network Protection Connectors - vertical cable leads, stud size 3 inch, outlets 8, 9.50 Height, 10.75 tower width
Aluminum Transformer Connector-CSW Series - Quick Disconnect, Cable Range 6-500, Stud Size 1 Inch, Insulator Length 7-3/16 inch, Outlets 4, Oxide Inhibitor

CSW 4500 C

Aluminum Transformer Connector-CSW Series - Quick Disconnect, Cable Range 6-500, Stud Size 1 Inch, Insulator Length 7-3/16 inch, Outlets 4, Oxide Inhibitor
Aluminum Transformer Connector-CSW Series - Quick Disconnect, Cable Range 12-350, Stud Size 5/8 Inch, Insulator Length 5-11/16 Inch, Outlets 4, Oxide Inhibitor

CSW 4350 C

Aluminum Transformer Connector-CSW Series - Quick Disconnect, Cable Range 12-350, Stud Size 5/8 Inch, Insulator Length 5-11/16 Inch, Outlets 4, Oxide Inhibitor
Aluminum Transformer Connector-CSW Series - Quick Disconnect, Cable Range 6-500, Stud Size 1 Inch, Insulator Length 7-3/16 inch, Outlets 4, Oxide Inhibitor And Street Light Outlet Option

CSW 4500 SLC

Aluminum Transformer Connector-CSW Series - Quick Disconnect, Cable Range 6-500, Stud Size 1 Inch, Insulator Length 7-3/16 inch, Outlets 4, Oxide Inhibitor And Street Light Outlet Option
Copper 175 Series Clamp-On Style Transformer and Network Protection Connectors - horizontal cable leads, height 9-3/8 inch stud size 1-1/2 inch, outlets 4

FTH 22-175-15 CU

Copper 175 Series Clamp-On Style Transformer and Network Protection Connectors - horizontal cable leads, height 9-3/8 inch stud size 1-1/2 inch, outlets 4
