ABB - Installation Products CSB 750-10 - Aluminum Multi-Tap Encapsulated Cable Blocks - Two-Way Configuration, Wire Range 750-1/0, Screw Size 3/8 Hex, Length 14-1/4 Inches, Width 3-3/8 Inches, Height 2-1/4 Inches, Outlets 10
ABB - Installation Products

CSB 750-10

UPC: 783786715084

Documents & Media
Manufacturer Product Website

Contact for Pricing

Overview

The ABB Installation Products CSB 750-10 is a two-way configured aluminum multi-tap encapsulated cable block designed for efficient and reliable electrical connections. This unit features 10 outlets, accommodating a wire range from 750 kcmil down to 1/0 AWG, ensuring versatility for various conductor sizes. The robust construction utilizes high-grade aluminum, providing excellent conductivity and corrosion resistance for long-term performance in industrial settings. Each tap is secured with a 3/8 inch hex screw, allowing for a firm and dependable connection. With a substantial length of 14-1/4 inches, a width of 3-3/8 inches, and a height of 2-1/4 inches, the CSB 750-10 offers ample space for organized wiring and secure encapsulation. This design is critical for maintaining electrical integrity and preventing environmental contamination of the connections. The encapsulated nature of the block provides protection against moisture, dust, and other contaminants, which is essential for applications in harsh or exposed environments. The series designation, CSB, signifies ABB's commitment to quality and functionality in their electrical distribution products. Key specifications include: - Manufacturer: ABB - Installation Products - SKU: CSB 750-10 - Material: Aluminum - Configuration: Two-Way Multi-Tap - Number of Outlets: 10 - Wire Range: 750 kcmil - 1/0 AWG - Screw Size: 3/8 Inch Hex - Dimensions: 14.25" (L) x 3.375" (W) x 2.25" (H) This cable block is suitable for power distribution applications where multiple conductors need to be terminated from a single source, such as in substations, industrial facilities, and utility infrastructure. The 10-pole configuration allows for significant branching of power, simplifying complex wiring layouts. The aluminum construction ensures efficient heat dissipation, contributing to the overall safety and reliability of the electrical system. The encapsulated design further enhances safety by isolating live components.
  • ABB CSB 750-10 Aluminum Multi-Tap Encapsulated Cable Block
  • Two-Way Configuration with 10 Outlets
  • Wire Range: 750 kcmil - 1/0 AWG
  • Screw Size: 3/8 Inch Hex
  • Dimensions: 14.25" L x 3.375" W x 2.25" H

Specifications

Color
Clear
Material
Aluminum
Special Features
Versatile design. Wide range of cable sizes and number of outlets available in one-way configurations
Standard
UL E9809
Type
Above Ground Pedestal Connectors & Covers
Voltage Rating
600 V
Wire Size
1/0 AWG-750 kcmil
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
3.3500 L
Package Weight (Metric)
1.5200 kg
