ABB - Installation Products BTC0208 - Type BTC - Copper Single-Conductor, One-Hole Mount (Offset-Tang), Conductor Range 8 Str-2 Str, Length 1-15/32, Width 1/2 Inch, Height 27/32 Inch, 17/64 Bolt Inch Hole

ABB Installation Products BTC0208 Type BTC - Copper Single-Conductor, One-Hole Mount (Offset-Tang), Conductor Range 8…

UPC: 783786611300

Documents & Media
Specification SheetManufacturer Product Website

Contact for Pricing

Minimum Qty: 10

Multiplier: 10

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB BTC0208 is a Type BTC copper single-conductor terminal engineered for secure one-hole mounting with an offset-tang configuration, optimized for efficient wire routing and reduced installation time. This terminal is specifically designed to accommodate conductor sizes ranging from 8 AWG to 2 AWG stranded copper, ensuring reliable electrical connections in a variety of industrial and commercial applications. The BTC0208 features precise dimensions, measuring 1-15/32 inches in length, 1/2 inch in width, and 27/32 inches in height, with a 17/64-inch bolt hole for secure attachment. The offset-tang design enhances alignment with mounting surfaces, minimizing alignment challenges during installation. Compatible with standard 1/4-inch bolts, the terminal provides stable and vibration-resistant connections, making it ideal for use in control panels, switchgear, motor control centers, and other electrical distribution systems where reliable conductor termination is critical. The copper construction delivers excellent conductivity and corrosion resistance, ensuring long-term performance even in harsh environments. This terminal is part of the ABB Installation Products line, recognized for durable and precise conductor termination in demanding applications. The Type BTC designation indicates its suitability for single-conductor installations, while the one-hole mount and offset-tang features contribute to its versatility and ease of use in various electrical systems.
  • Accommodates conductor sizes from 8 AWG to 2 AWG stranded copper
  • One-hole mounting with offset-tang configuration for efficient wire routing
  • Dimensions: 1-15/32" L x 1/2" W x 27/32" H, 17/64" bolt hole
  • Copper construction for excellent conductivity and corrosion resistance
  • Ideal for control panels, switchgear, and motor control centers

Specifications

Material
Copper
Special Features
Uniquely designed pressure bar and notched v-bottom collar provide vise-like grip between conductor and terminal
Standard
UL E9809
Type
Copper Connectors
Package Dimensions (L x W x H)
3 IN x 2.5 IN x 2 IN
Package Dimensions (L x W x H)
7.62 cm x 6.35 cm x 5.08 cm
Package Weight (Imperial)
0.0500 L
Package Weight (Metric)
0.0230 kg
