ABB - Installation Products B/PG13/90 - 90 Degree Brass Elbow, PG13.5 External Thread to M20 Internal Thread, Nickel Plated Brass
ABB - Installation Products

B/PG13/90

UPC: 786210268088

Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 10

Multiplier: 10

*Contact for lower quantities*

Overview

The ABB B/PG13/90 90 Degree Brass Elbow is a premium industrial fitting engineered for robust performance and exceptional durability. Manufactured by ABB - Installation Products, this elbow (SKU: B/PG13/90) features a precise 90-degree bend, facilitating efficient directional changes in conduit and cable management systems. Its construction utilizes high-grade brass, enhanced with a nickel-plated finish for superior resistance to corrosion and environmental degradation, ensuring extended service life even in demanding industrial settings. The fitting is designed with a PG13.5 external thread on one end, specifically for connecting to compatible PG glands or conduits, and an M20 internal thread on the other, allowing for secure integration with M20 threaded entries. This versatile thread combination makes the B/PG13/90 ideal for a wide array of applications, including: * Industrial automation and control systems * Electrical installations in harsh environments * Fluid and gas handling systems requiring secure connections * Instrumentation and sensor wiring
  • 90-degree bend for directional changes
  • PG13.5 external thread for conduit/gland connection
  • M20 internal thread for secure entry
  • Nickel-plated brass construction for corrosion resistance
  • Durable and reliable for industrial applications

Specifications

Application
Connecting Two Pieaces of Conduit at an Angle
Material
Nickel Plated Brass
Material Quality
Nickel Plated Brass
Special Features
Designed to Help Maintain System Integrity
Trade Size
PG13.5 to M2
Type
90 Degree Elbow
Package Dimensions (L x W x H)
1 IN x 5.9 IN x 7.87 IN
Package Dimensions (L x W x H)
2.54 cm x 14.986 cm x 19.9898 cm
Package Weight (Imperial)
0.170 L
Package Weight (Metric)
0.077 kg
