ABB - Installation Products ABW 4500 C - Aluminum Quick Disconnect Transformer Connectors - ABW In-Line Bar, Cable Range 6-500, Length 6-1/16 Inch, Boot No. Sb 2163-38, Stud Size 1, Outlets 4, Oxide Inhibitor

ABB Installation Products ABW 4500 C Aluminum Quick Disconnect Transformer Connectors - ABW In-Line Bar, Cable Range 6-500…

UPC: 783786689477


Documents & Media
Manufacturer Product Website

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB ABW 4500 C is an aluminum quick disconnect transformer connector designed for in-line bar applications. This connector supports cable ranges from 6 to 500 kcmil, making it suitable for medium to high-current transformer connections. The unit measures 6-1/16 inches in length and features four outlets for parallel conductor terminations. The connector includes an integrated oxide inhibitor to prevent corrosion at the contact interface, ensuring long-term electrical integrity. The stud size is 1 inch, providing a secure mechanical connection. The included boot (SB 2163-38) offers environmental protection against moisture and contaminants. This connector is ideal for transformer installations in industrial, utility, and commercial power distribution systems where reliable, quick-connect/disconnect functionality is required. The aluminum construction ensures lightweight durability while maintaining high conductivity. The 4-outlet design allows for flexible conductor routing and simplifies maintenance by enabling rapid disconnection without tools.
  • Cable range: 6 to 500 kcmil for medium to high-current applications
  • Length: 6-1/16 inches for compact transformer installations
  • 4 outlets for parallel conductor terminations
  • Includes oxide inhibitor to prevent corrosion at contact points
  • Stud size: 1 inch for secure mechanical connection
  • Boot (SB 2163-38) provides environmental protection
  • Aluminum construction for lightweight durability and high conductivity
  • Quick disconnect design enables tool-free maintenance and replacement

Specifications

Application
Stud Mount Transformer Connector
Conductor Range
#6 to 500 kcmil
Connection
Mechanical
Connection Type
Quick Disconnect
Insulation
True
Material
Aluminum
Number of Conductors
4
Poles
4
Series
ABW In-Line Bar
Size
6-500
Special Features
In-Line Bar Series. Dual Rated for Aluminum and Copper Conductors. High Strength Aluminum Alloy maintains constant bolting pressure on Conductors. Quick Disconnectability for easy removal from transformer secondary studs. Ball-bottom screws ensure maximum conductor contact pressure and break up interstrand oxides
Standard
ANSI C119.4
Type
Quick-Disconnect Transformer Connector
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
0.9000 L
Package Weight (Metric)
0.4080 kg
Aluminum Quick Disconnect Transformer Connector, 6 Position, 8.328 Long, 6-500 MCM, Right Hand With PVC Cover

RAU 6500-6868 R-1

Aluminum Quick Disconnect Transformer Connector, 6 Position, 8.328 Long, 6-500 MCM, Right Hand With PVC Cover
Aluminum Quick Disconnect Transformer Connectors - ABW In-line bar, cable range 1/0-750, length 9-1/8 inch, boot no. SB 2157, stud size 5/8 inch, outlets 5

ABW 5750-58

Aluminum Quick Disconnect Transformer Connectors - ABW In-line bar, cable range 1/0-750, length 9-1/8 inch, boot no. SB 2157, stud size 5/8 inch, outlets 5
Aluminum Quick Disconnect Transformer Connectors - ABW In-line bar, cable range 12-350, length 7-1/2 inch, boot no. SB 11, stud size 5/8, outlets 6, Oxide Inhibitor

ABW 6350 C

Aluminum Quick Disconnect Transformer Connectors - ABW In-line bar, cable range 12-350, length 7-1/2 inch, boot no. SB 11, stud size 5/8, outlets 6, Oxide Inhibitor
Aluminum Quick Disconnect Transformer Connectors - ABW In-line bar, cable range 12-350, length 8-9/16 inch, boot no. SB 11, stud size 1, outlets 6, Oxide Inhibitor

ABW 6350-1 C

Aluminum Quick Disconnect Transformer Connectors - ABW In-line bar, cable range 12-350, length 8-9/16 inch, boot no. SB 11, stud size 1, outlets 6, Oxide Inhibitor
Aluminum Quick Disconnect Transformer Connectors - ABW In-line bar, cable range 6-500, length 8-1/18 inch, boot no. SB 2157 stud size 1, outlets 6, Oxide Inhibitor

ABW 6500 C

Aluminum Quick Disconnect Transformer Connectors - ABW In-line bar, cable range 6-500, length 8-1/18 inch, boot no. SB 2157 stud size 1, outlets 6, Oxide Inhibitor
Aluminum Quick Disconnect Transformer Connectors - ABW In-line bar, cable range 6-500, length 8-1/18 inch, boot no. SB 2157 stud size 5/8 inch, outlets 6

ABW 6500-58

Aluminum Quick Disconnect Transformer Connectors - ABW In-line bar, cable range 6-500, length 8-1/18 inch, boot no. SB 2157 stud size 5/8 inch, outlets 6
Aluminum Quick Disconnect Transformer Connectors - ABW In-line bar, cable range 6-500, length 8-1/18 inch, boot no. SB 2157 stud size 5/8 inch, outlets 6, Oxide Inhibitor

ABW 6500-58 C

Aluminum Quick Disconnect Transformer Connectors - ABW In-line bar, cable range 6-500, length 8-1/18 inch, boot no. SB 2157 stud size 5/8 inch, outlets 6, Oxide Inhibitor
Aluminum Quick Disconnect Transformer Connectors - ABW In-line bar, cable range 12-350, length 9-1/2 inch, boot no. SB 2160, stud size 5/8, outlets 8, Oxide Inhibitor

ABW 8350 C

Aluminum Quick Disconnect Transformer Connectors - ABW In-line bar, cable range 12-350, length 9-1/2 inch, boot no. SB 2160, stud size 5/8, outlets 8, Oxide Inhibitor
