ABB - Installation Products ABT 8500 - Aluminum Transformer Spade Connectors - ABT Single Set Screws Series - Double-Row Mounting Holes, conductor range 6-500, length 9-1/4 in, mounting holes 12, outlets 8

ABB Installation Products ABT 8500 Aluminum Transformer Spade Connectors - ABT Single Set Screws Series - Double-Row…

UPC: 783786689194

Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 10

Multiplier: 10

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

ABB ABT 8500 Aluminum Transformer Spade Connectors are designed for high-current electrical connections in transformer installations. These connectors feature a double-row mounting hole configuration (12 total) for secure attachment to busbars or transformer terminals. The 9-1/4-inch length accommodates conductor ranges from 6 AWG to 500 MCM, making them suitable for both primary and secondary transformer connections. The connectors are constructed from high-conductivity aluminum, ensuring efficient current transfer with minimal voltage drop. The spade terminal design allows for easy installation and removal using standard hardware, reducing downtime during maintenance or upgrades. The 8 outlets provide flexibility for parallel conductor configurations or multiple connection points. These connectors are commonly used in utility substations, industrial power distribution systems, and commercial transformer installations where reliable, high-current connections are critical. The double-row mounting holes improve mechanical stability, while the aluminum construction resists corrosion in outdoor or harsh environments. For applications requiring UL-listed components, verify local compliance as these connectors are designed for industrial-grade installations.
  • Conductor range: 6 AWG to 500 MCM
  • Length: 9-1/4 inches
  • Double-row mounting holes: 12 total
  • 8 outlets for parallel conductor configurations
  • High-conductivity aluminum construction

Specifications

Application
Pad Mount Transformer Connector
Conductor Range
#6 to 500 kcmil
Connection
Mechanical
Insulation
False
Material
Aluminum
Number of Conductors
8
Special Features
Single Set-Screw Series. High Strength Aluminum Alloy maximizes electrical and Mechanical Performance. Ball-Bottom screws ensure Maximum Conductor Contact pressure and break up interstrand oxides. Dual rated to accept Copper or Aluminum conductors
Standard
ANSI C119.4
Type
Transformer Spade Connector
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
2.4600 L
Package Weight (Metric)
1.1160 kg
