ABB - Installation Products ABT 6500 C - Aluminum Transformer Spade Connectors - ABT Sinkhole Set Screws Series - Double-row Mounting Holes, Conductor Range 6-500, Length 6-1/2 Inch, Mounting Holes 8, Outlets 6, Oxide Inhibitor

ABB Installation Products ABT 6500 C Aluminum Transformer Spade Connectors - ABT Sinkhole Set Screws Series - Double-row…

UPC: 783786689057


Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 10

Multiplier: 10

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB ABT 6500 C Aluminum Transformer Spade Connectors are engineered for high-current electrical connections in transformer installations. These connectors feature a 6-500 AWG conductor range, making them suitable for heavy-duty applications where reliable power distribution is critical. The double-row mounting holes provide enhanced stability and secure attachment to transformer terminals, reducing the risk of loosening under vibration or thermal cycling. With six outlets, the ABT 6500 C supports multi-conductor terminations, streamlining wiring configurations in compact spaces. The set screw connection design ensures a tight, low-resistance joint, minimizing heat generation and voltage drop. Constructed from high-quality aluminum, these connectors offer excellent conductivity and corrosion resistance, extending service life in harsh industrial environments. The oxide inhibitor treatment further enhances reliability by preventing oxidation at the contact points, ensuring consistent performance over time. Ideal for transformer secondary connections, switchgear, and distribution panels, the ABT 6500 C delivers durable, high-efficiency performance in demanding electrical systems. Compatible with standard transformer terminals, these connectors simplify installation and maintenance while meeting industry safety and performance standards.
  • Aluminum construction for high conductivity and corrosion resistance
  • Conductor range: 6-500 AWG for heavy-duty applications
  • 6 outlets with set screw connections for multi-conductor terminations
  • Double-row mounting holes for secure and stable attachment
  • Oxide inhibitor treatment to prevent contact oxidation

Specifications

Application
Pad Mount Transformer Connector
Conductor Range
#6 to 500 kcmil
Connection
Mechanical
Insulation
False
Material
Aluminum
Number of Conductors
6
Special Features
Single Set-Screw Series. High Strength Aluminum Alloy maximizes electrical and Mechanical Performance. Ball-Bottom screws ensure Maximum Conductor Contact pressure and break up interstrand oxides. Dual rated to accept Copper or Aluminum conductors
Standard
ANSI C119.4
Type
Transformer Spade Connector
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
1.7300 L
Package Weight (Metric)
0.7850 kg
