ABB - Installation Products A87 - Non-Insulated Ring Terminal, Length .75 Inches, Width .31 Inches, Bolt Hole #10, Wire Range #22-#16 AWG, Copper, Tin Plated, 1,000 Pack
ABB - Installation Products

A87

UPC: 786210807928

Documents & Media
Specification SheetManufacturer Product Website

Contact for Pricing

Minimum Qty: 1000

Multiplier: 1000

*Contact for lower quantities*

Overview

The ABB A87 Non-Insulated Ring Terminal is a precision-engineered electrical termination solution designed for secure, high-reliability connections in industrial and commercial electrical systems. This terminal features a durable tin-plated copper construction with a #10 bolt hole, accommodating #22 to #16 AWG copper wires for versatile applications. The .75-inch length and .31-inch width provide optimal clearance and mounting flexibility, while the brazed seam construction ensures barrel integrity during crimping, preventing splitting or deformation. Internal barrel serrations deliver consistent wire contact and maximum tensile strength, critical for high-vibration environments such as control panels, switchgear, and motor control centers. The terminal is UL and CSA rated for up to 2000V per UL 486A/B standards, with a maximum operating temperature of 105°C (221°F), ensuring compliance with stringent electrical safety requirements. Packaged in a bulk 1,000-piece quantity, the A87 offers cost-effective scalability for large-scale installations, reducing per-unit costs while maintaining ABB's reputation for quality and reliability. Ideal for grounding, bonding, and power distribution systems where secure, long-lasting terminations are essential.
  • Tin-plated copper construction for corrosion resistance and conductivity
  • Brazed seam prevents barrel splitting during crimping
  • Internal serrations ensure consistent wire contact and tensile strength
  • UL and CSA rated for 2000V per UL 486A/B, 105°C max operating temperature
  • Compatible with #22-#16 AWG copper wires, #10 bolt hole size

Specifications

Color
Metallic
Material
Copper
Special Features
These non-insulated ring terminals are made of electrolytic copper for high conductivity. They can be installed with crimping tools having a single indentor or double indentor (recommended for solid wire). Serrated barrel increases grip on wire
Standard
UL E9809 / UL E9809
Type
Non-Insulated Ring Terminal
Voltage Rating
600 V
Wire Size
22-16 AWG
Package Dimensions (L x W x H)
3.5 IN x 3 IN x 3 IN
Package Dimensions (L x W x H)
8.89 cm x 7.62 cm x 7.62 cm
Package Weight (Imperial)
0.001 L
Package Weight (Metric)
0.001 kg
