ABB - Installation Products 60256 - Aluminum Two-Hole Lug, Long Barrel, Blind End, Max 35kV, 250 kcmil Wire, 1/2 Inch Bolt Size, 1-3/4 Inch Hole Spacing, Tin Plated, Die Code 71H, Die Color Code Red
ABB - Installation Products

60256

UPC: 786210602561

Documents & Media
Installation InstructionsSpecification SheetManufacturer Product Website

Contact for Pricing

Minimum Qty: 5

Multiplier: 5

*Contact for lower quantities*

Overview

The ABB 60256 is a high-conductivity, wrought aluminum two-hole lug designed for reliable electrical connections in demanding industrial applications. This long barrel lug features an enclosed barrel design, factory pre-filled with joint compound and sealed with an easy pull-out end plug, effectively inhibiting corrosion and preventing contaminants from entering the barrel. Its tin-plated finish further enhances corrosion resistance, ensuring long-term durability. Rated for up to 35kV and temperature rated to 90°C, the ABB 60256 is cULus listed when crimped with specified Panduit and competitor tools and dies. It is engineered to accommodate 250 kcmil stranded aluminum or copper code conductors. The lug features a 1/2 inch stud hole size and a 1-3/4 inch hole spacing, compatible with NEMA standards. Color-coded barrel markings, including the red die code 71H, facilitate proper crimp die selection for optimal performance and traceability. This lug meets Telcordia NEBS Level 3 testing and is American Bureau of Shipping approved. Ideal for power distribution systems, industrial machinery, and electrical infrastructure projects requiring robust and dependable termination solutions. SKU: 60256. UNSPSC: 39121405.
  • Manufactured from high-conductivity wrought aluminum with a thick wall.
  • Enclosed barrel design with factory pre-filled joint compound inhibits corrosion.
  • Tin-plated finish for enhanced corrosion resistance.
  • cULus listed to 35kV and temperature rated to 90°C.
  • Color-coded barrel with Panduit and competitor die index numbers for proper crimp die selection (Red Die Code 71H).

Specifications

Cable Size
250 kcmil
Color
Red
Insulation
None
Material
Aluminum
Number Of Holes
2
Standard
UL E9809
Standard
UL E9809 / UL E9809
Stud Size
1/2 in
Type
Long Barrel
Voltage Rating
35 kV
Package Dimensions (L x W x H)
6 IN x 4.5 IN x 3 IN
Package Dimensions (L x W x H)
15.24 cm x 11.43 cm x 7.62 cm
Package Weight (Imperial)
0.210 L
Package Weight (Metric)
0.095 kg
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.

OD581

Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
O' Die for OD581 Mechanical Crimp Tool

OJB

O' Die for OD581 Mechanical Crimp Tool
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.

CD6A

U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.

CD7

U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic

E6-PS-D

Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.

AS-K1-H6

Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
PVC Coated Junction Box, 12 Inch X 12 Inch X 6 Inch, 14 Gauge, Gray

A1212SC-G

PVC Coated Junction Box, 12 Inch X 12 Inch X 6 Inch, 14 Gauge, Gray
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray

E989NNJ-5-HD

Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

1SNK705010R0000

Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

1SNK705030R0000

Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

How to Install the 60248 Aluminum Lugs

This guide provides step-by-step instructions for installing 60248 aluminum lugs, ensuring a secure and reliable electrical connection.

Estimated time: 45m

Tools needed:

Screwdriver, Wire strippers, Multimeter

Supplies needed:

Mounting screws, Terminal connectors, Joint compound, Shrink tubing

  1. Prepare the cable

    Strip the insulation from the cable to the length specified in the installation table. Avoid nicking the cable strands.

  2. Insert the cable into the connector

    Remove the plastic protective cap from the wire barrel. Smear a thin layer of joint compound onto the cable, then insert the cable into the connector until it stops, ensuring the insertion length matches the stripped cable length.

  3. Crimp the connector

    Place the connector in the appropriate crimping die as per the installation table. Compress the connector, starting near the tongue, and ensure the required number of compressions is achieved.

  4. Remove sharp edges

    After crimping, carefully remove any sharp edges, flash, or burrs that may have resulted from the crimping process.

  5. Install the lug

    Bolt the lug to the mounting pad using the specified mounting screws. Use a Belleville compression washer to maintain tension and compensate for thermal expansion.

  6. Insulate the connection

    Use shrink tubing or another approved insulation method to cover the connection, ensuring it is secure and protected from environmental factors.
