Contact for Pricing
Minimum Qty: 6
Multiplier: 6
*Contact for lower quantities*
Overview
- Rated for 600V to 35kV applications
- Accommodates 400 kcmil copper conductors
- 1/2" bolt size with 1-3/4" hole spacing
- Tin-plated finish for corrosion resistance
- Peep hole for visual conductor verification
Specifications
Cable Size | 400 kcmil |
Color | Blue |
Connection Type | Bolt connection |
Connection Type | Bolt |
Connection Type | Two-Hole Lug |
Insulation | None |
Material | Copper |
Material | Copper, Tin Plated |
Mounting Type | Long Barrel, Peep Hole |
Mounting Type | Bolted |
Mounting Type | Bolt |
Mounting Type | Bolt Mount |
Mounting Type | Two-hole mounting |
Mounting Type | Two-Hole |
Mounting Type | Peep Hole |
Mounting Type | Two-Hole Lug |
Number Of Holes | 2 |
Series | 54874BE |
Series | 76 |
Series | ABB Installation Products |
Size | 400 kcmil, 1/2 Inch Bolt Size, 1-3/4 Inch Hole Spacing |
Size | 400 kcmil |
Size | 400 kcmil, 1/2 Inch Bolt, 1-3/4 Inch Hole Spacing |
Stud Size | 1/2 in |
Type | Long Barrel |
Voltage Rating | 35 kV |
Package Dimensions (L x W x H) | 600 IN x 450 IN x 300 IN |
Package Dimensions (L x W x H) | 1524 cm x 1143 cm x 762 cm |
Package Weight (Imperial) | 0.440 L |
Package Weight (Metric) | 0.200 kg |
RDC1/0
Ratchet Drive Crimping Tool APPLICATIONS: Ratchet Drive Crimping Tool is for non-insulated terminals from 6 to 1/0 AWG and insulated terminals from 22 to 8 AWG. Rugged, compact, and lightweight. Requires minimum effort due to ratchet action, ensuring an excellent crimp every time. FEATURES: TYPE: Insulated and Uninsulated ACTION: Ratchet INSULATED USE: Terminals 22 to 8 AWG NON-INSULATED USE: Terminals 6 to 1/0 AWG MANUFACTURER: NSi Industries PART NUMBER: RDC 1/0 UPC: 662381055309
CD6A
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
13682
Die for 12 Ton 13400 or 13642M Hydrualic Tool for Crimping 204210MT Dragon Tooth Terminals, Brown. .301/.289 Gaging
F4-PS-W-NP
Non-Insulated Parallel Splice Connector For Wire Range #4 AWG, Circular Mil Range 33,100-52,600, Length 0.531 Diameter 0.41, Nickel Plated
AS-K1-H6
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
E989NNJ-5-HD
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
1SNK705030R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
Frequently Asked Questions
How should the product be installed?
Installation must comply with applicable national and local electrical codes.
What suffix indicates a connector with a peep hole?
Suffix 'PH' denotes a part with an inspection hole (peep hole).
What suffix indicates a blank tongue connector?
Suffix 'BT' denotes a blank tongue connector.
What is the maximum operating voltage?
The product operates at a maximum voltage of 35kV.
What materials are used in the connectors?
The connectors are made from high conductivity copper and are electro-tin plated unless otherwise specified.
What types of conductors are compatible?
The connectors are suitable for copper cable conductors classified as G, H, I, K, and M.
What is the crimping tool requirement?
Different die halves require specific crimping tools, such as the 6TONXSS for 6TON-series dies.
Are there safety warnings for this product?
The product must be installed according to electrical codes to ensure safety.
What is the temperature range for operation?
The document does not specify a temperature range for operation.
What are the maintenance requirements?
The document does not specify any maintenance requirements for the product.
