ABB - Installation Products 54224 - Copper Two-Hole Lug, Standard Barrel, Peep Hole, Max 35kV, Wire Size 800 kcmil, 1/2 Inch Bolt Size, 1-3/4 Inch Hole Spacing, Tin Plated, Die Code 107, Die Color Code Orange
ABB - Installation Products

54224

UPC: 786210542249

Documents & Media
Installation InstructionsSpecification SheetManufacturer Product Website

Contact for Pricing

Minimum Qty: 3

Multiplier: 3

*Contact for lower quantities*

Overview

The ABB Copper Two-Hole Lug (SKU: 54224) is a high-performance electrical connector designed for demanding industrial applications. Featuring a standard barrel with a peep hole, this lug is rated for a maximum voltage of 35kV, ensuring reliable performance in high-voltage systems. Constructed from high-quality copper and tin-plated for enhanced corrosion resistance, it accommodates wire sizes up to 800 kcmil and features a 1/2-inch bolt size with a 1-3/4-inch hole spacing. The orange die color code and die code 107 make it easy to identify and inventory. Ideal for utility, industrial, and commercial electrical installations, this lug provides secure and efficient connections, reducing installation time and ensuring long-term durability.
  • High-voltage rated up to 35kV for demanding electrical applications
  • Constructed from durable copper with tin plating for corrosion resistance
  • Accommodates wire sizes up to 800 kcmil for versatile use
  • Standard barrel design with peep hole for easy installation and inspection
  • 1/2-inch bolt size with 1-3/4-inch hole spacing for secure connections

Specifications

Cable Size
800 kcmil
Color
Orange
Insulation
None
Material
Copper
Number Of Holes
2
Standard
UL E9809
Standard
UL E9809 / UL E9809
Stud Size
1/2 in
Type
Standard Barrel
Voltage Rating
35 kV
Package Dimensions (L x W x H)
6 IN x 4.5 IN x 3 IN
Package Dimensions (L x W x H)
15.24 cm x 11.43 cm x 7.62 cm
Package Weight (Imperial)
0.900 L
Package Weight (Metric)
0.408 kg
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.

OD581

Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
O' Die for OD581 Mechanical Crimp Tool

OJB

O' Die for OD581 Mechanical Crimp Tool
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.

CD6A

U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.

CD7

U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic

E6-PS-D

Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
Non-Insulated Butt Splice, Length 0.63 Inches, Width 0.13 Inches, Wire Range 22-18 AWG, Copper, Tin Plated, 100 Pack

2A-18

Non-Insulated Butt Splice, Length 0.63 Inches, Width 0.13 Inches, Wire Range 22-18 AWG, Copper, Tin Plated, 100 Pack
PVC Coated Junction Box, 12 Inch X 12 Inch X 6 Inch, 14 Gauge, Gray

A1212SC-G

PVC Coated Junction Box, 12 Inch X 12 Inch X 6 Inch, 14 Gauge, Gray
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray

E989NNJ-5-HD

Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

1SNK705010R0000

Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

1SNK705030R0000

Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

How to Install the 54224 Connector

This guide provides step-by-step instructions for installing the 54224 connector, ensuring proper crimping and insulation for reliable electrical connections.

Estimated time: 30m

Tools needed:

Wire strippers, Crimping tool, Multimeter

Supplies needed:

54224 connector, Cable, Insulation materials (adhesive pad or shrink tubing)

  1. Prepare the cable

    Strip the insulation from the cable to the specified length in the installation table. Avoid nicking the cable strands to prevent breakage.

  2. Insert the cable into the connector

    Clean the cable end with a wire brush, then insert it into the 54224 connector until it stops. Use the inspection peep hole to confirm that the cable is fully inserted.

  3. Crimp the connector

    Place the connector in the crimping tool and compress it according to the markings, starting near the tongue of the connector. Refer to the installation table for the required number of compressions.

  4. Remove sharp edges

    After crimping, carefully remove any sharp edges, flash, or burrs from the connector to ensure safety and proper installation.

  5. Insulate the connection

    Apply insulation to the crimped area using either an adhesive pad or shrink tubing as specified in the installation table.
