Contact for Pricing
Minimum Qty: 10
Multiplier: 10
*Contact for lower quantities*
Overview
- 90-degree bend standard barrel for efficient wire routing
- Rated for maximum 35kV voltage applications
- Tin-plated finish for corrosion resistance in harsh environments
- Peep hole for visual inspection of wire termination
- 1/4-inch bolt size compatible with standard mounting hardware
Specifications
Cable Size | 1/0 AWG |
Color | Pink |
Connection Type | Peep Hole for Wire Insertion |
Connection Type | Peep Hole (for visual inspection) |
Connection Type | 90 Degree Bend, Peep Hole |
Connection Type | One-Hole Lug, 90 Degree Bend |
Connection Type | Lug |
Connection Type | Bolt |
Insulation | None |
Material | Copper |
Material | Copper, Tin Plated |
Mounting Type | One-Hole, 90 Degree Bend |
Mounting Type | Bolt Mount |
Mounting Type | 90 Degree Bend |
Mounting Type | Bolt |
Number Of Holes | 1 |
Series | 54152 |
Size | 1/0 AWG |
Size | 1/0 AWG, 1/4 Inch Bolt |
Size | 1/0 AWG, 1/4 Inch Bolt Size |
Size | 1/0 AWG, 1/4 Inch Bolt Size, 90 Degree Bend |
Size | Standard Barrel |
Standard | UL E9809 / UL E9809 |
Standard | UL E9809 |
Stud Size | 1/4 in |
Type | Standard Barrel 90 Degree Bend |
Voltage Rating | 35kV |
Voltage Rating | 35 kV |
Package Dimensions (L x W x H) | 0.01 IN x 0.01 IN x 0.01 IN |
Package Dimensions (L x W x H) | 0.0254 cm x 0.0254 cm x 0.0254 cm |
Package Weight (Imperial) | 0.010 L |
Package Weight (Metric) | 0.005 kg |
OD581
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
CD6A
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
CD7
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
E6-PS-D
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
AS-K1-H6
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
E989NNJ-5-HD
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
1SNK705030R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
How to Install the 54152UB Connector
This guide provides step-by-step instructions for installing the 54152UB connector, ensuring proper crimping and insulation for reliable electrical connections.
Estimated time: 30m
Tools needed:
Wire strippers, Crimping tool, Multimeter
Supplies needed:
54152UB connectors, Cable, Shrink tubing, Insulation pad
- Prepare the cable
Strip the insulation from the cable to the specified length, ensuring not to nick any strands. Clean the cable end with a wire brush.
- Insert the cable into the connector
Insert the prepared cable end into the 54152UB connector until it stops. Use the inspection peep hole to confirm that the cable is fully inserted.
- Crimp the connector
Place the connector in the crimping tool and compress it according to the markings, ensuring a secure connection. Follow the manufacturer's specifications for the number of compressions required.
- Remove sharp edges
After crimping, carefully remove any sharp edges, flash, or burrs from the connector to prevent injury or damage.
- Insulate the connection
Apply insulation using the method specified in the documentation, ensuring that all exposed metal is covered to prevent short circuits.
