ABB - Installation Products 54136UB - Copper One-Hole Lug, 90 Degree Bend Standard Barrel, Peep Hole, Max 35kV, Wire Size #6 AWG, 3/8 Inch Bolt Size, Tin Plated, Die Code 24, Die Color Code Blue
ABB - Installation Products

54136UB

UPC: 786210594842

Documents & Media
Specification SheetManufacturer Product Website

Contact for Pricing

Overview

The ABB 54136UB is a high-quality, one-hole copper lug designed for secure electrical connections in demanding industrial environments. Engineered by ABB Installation Products, this lug is rated for up to 35 kV, making it suitable for medium-voltage applications. Its standard barrel features a peep hole, allowing for visual inspection of wire insertion and ensuring a complete connection. The lug is constructed from premium copper for excellent conductivity and is tin-plated to provide superior corrosion resistance and long-term reliability. The 90-degree bend design of the ABB 54136UB facilitates efficient routing of conductors in confined spaces or panel layouts, contributing to streamlined installation processes. This one-hole lug is specifically engineered to accommodate wire sizes up to #6 AWG, offering broad compatibility with common conductor gauges. The termination point is designed for a 3/8-inch bolt size, ensuring secure fastening with standard hardware. For straightforward identification and inventory management, the ABB 54136UB is clearly marked with a blue color code, which corresponds to Die Code 24. This precise die code and color coding system aids in ensuring the correct tooling is used during installation, further enhancing the reliability of the connection. The robust construction and precise manufacturing inherent in ABB Installation Products ensure dependable performance in critical electrical systems. The tin plating on the copper lug offers enhanced protection against environmental factors, contributing to its longevity and consistent electrical performance over time. The standard barrel design, coupled with the peep hole feature, provides a visual confirmation of proper wire insertion, minimizing the risk of improper termination and potential connection failures. The 54136UB is a testament to ABB's commitment to providing durable, safe, and efficient electrical terminations for a wide range of applications.
  • Rated for 35 kV for medium-voltage applications
  • Constructed from tin-plated copper for excellent conductivity and corrosion resistance
  • Accommodates wire sizes up to #6 AWG
  • Features a 3/8-inch bolt size for secure termination
  • 90-degree bend design for efficient conductor routing

Specifications

Cable Size
6 AWG
Color
Blue
Insulation
None
Material
Copper
Number Of Holes
1
Standard
UL E9809
Standard
UL E9809 / UL E9809
Stud Size
3/8 in
Type
Standard Barrel 90 Degree Bend
Voltage Rating
35 kV
Package Dimensions (L x W x H)
3.25 IN x 2.75 IN x 2.25 IN
Package Dimensions (L x W x H)
8.255 cm x 6.985 cm x 5.715 cm
Package Weight (Imperial)
0.020 L
Package Weight (Metric)
0.009 kg
