ABB - Installation Products 5323 - 1 Inch Insulated Compression Connector, Steel Electro Zinc Plated, Insulator Thermoplastic for Use with EMT Conduit

ABB Installation Products 5323 1 Inch Insulated Compression Connector, Steel Electro Zinc Plated, Insulator…

UPC: 786210053233

Documents & Media
Specification SheetManufacturer Product Website

Contact for Pricing

Minimum Qty: 25

Multiplier: 25

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB 5323 1-inch Insulated Compression Connector is a high-integrity electrical fitting engineered for secure, long-lasting connections with EMT (Electrical Metallic Tubing) conduit. Manufactured by ABB - Installation Products, this connector combines a steel body with an electro-zinc plated finish and a thermoplastic insulator to deliver superior corrosion resistance, electrical insulation, and mechanical durability in industrial and commercial applications. Key construction details include a steel body with electro-zinc plating, providing a protective barrier against rust and environmental degradation—critical for installations exposed to moisture, chemicals, or outdoor conditions. The thermoplastic insulator ensures electrical isolation, heat resistance, and impact durability, maintaining system integrity under operational stress. This connector is specifically designed for 1-inch EMT conduit, ensuring a precise, tight fit that minimizes signal loss and ensures a stable electrical path. The compression-style connection design delivers mechanical strength and superior electrical conductivity, reducing the risk of loose connections or signal degradation over time. This design is ideal for applications requiring reliable, maintenance-free performance, such as industrial facilities, commercial buildings, and infrastructure projects where electrical continuity and safety are paramount. Packaged in inner packs of 25 and outer packs of 100, the ABB 5323 is optimized for efficient inventory management and bulk deployment. The product is part of ABB’s comprehensive line of EMT compression fittings, which includes sizes from ½-inch to 4-inch, offering flexibility for diverse conduit systems. The UL File No. Use this connector in new installations or retrofits where a secure, insulated, and corrosion-resistant connection is required for EMT conduit systems. Its design supports fast, tool-assisted installation, reducing labor time while ensuring a professional-grade result.
  • 1-inch size for EMT conduit compatibility
  • Steel body with electro-zinc plating for corrosion resistance
  • Thermoplastic insulator for electrical insulation and impact resistance
  • Compression-style connection for mechanical strength and electrical conductivity
  • Inner pack: 25 units, Outer pack: 100 units

Specifications

Application
To Connect and Effectively Bond Electrical Metallic Tubing to a Box or an Enclosure
Finish
Electro Zinc Plated
Material Quality
Steel
Size
1 Inch
Special Features
Rugged All Steel Construction
Standard
UL E16592, CSA
Type
EMT Conduit Fittings
Package Dimensions (L x W x H)
4 IN x 4.5 IN x 6 IN
Package Dimensions (L x W x H)
10.16 cm x 11.43 cm x 15.24 cm
Package Weight (Imperial)
0.2300 L
Package Weight (Metric)
0.1040 kg
