UPC: 067396007617
Documents & Media
Contact for Pricing
Minimum Qty: 10000
Multiplier: 10000
*Contact for lower quantities*
Overview
- Compatible with 18-14 AWG solid or stranded copper wires
- Rated for high-temperature environments up to 105°C
- Bulk packaging for large-scale installations
- Vibration-resistant connection for long-term reliability
- UL and CSA certified for electrical safety
Specifications
Color | Black |
Material | Thermoplastic Polymer |
Size | Min 1 #22 + 1 #20, Max 3 #16 |
Special Features | External cap made of rugged, phenolic material and 150 degree C rated |
Standard | UL E9809, CSA 6591 |
Temperature Rating, Maximum | 302 F |
Temperature Rating, Maximum | 150 C |
Temperature Rating, Minimum | 302 F |
Temperature Rating, Minimum | 150 C |
Type | High Temperature Wire Connectors |
Voltage Rating | 600 V |
Package Dimensions (L x W x H) | 0.01 IN x 0.01 IN x 0.01 IN |
Package Dimensions (L x W x H) | 0.0254 cm x 0.0254 cm x 0.0254 cm |
Package Weight (Imperial) | 0.0010 L |
Package Weight (Metric) | 0.0010 kg |
WC-HB3-B
The Easy-Twist WC-HB3-B 500-Count Bag of High Temperature Black Wire Connectors are designed for use on copper wires in the 22-14 AWG size range. They’re made of flame-retardant thermoplastic rated for a maximum temperature of 150˚ Celsius (302˚ Fahrenheit). The quick-grip square spring design grips in fewer twists and can dead-end a single wire, while the ergonomic ribbed texture makes them easy to twist. Their compact design is useful for applications in tight areas or anywhere else you need to connect wires.
30BK
Twist-on Wire Connector, Black, high temperature wire connector wire range #22-#14. Made of rugged, thermoplastic polymer material 150 Degree C (302 Degree F) rated. Approved for circuit and fixture type connections up to 300 V only. For copper conductor only. Bulk Package of 1500 pieces.
30BP
Twist-on Wire Connector, Black, high temperature wire connector wire range #22-#14. Made of rugged, thermoplastic polymer material 150 Degree C (302 Degree F) rated. Approved for circuit and fixture type connections up to 300 V only. For copper conductor only. Package of 1000 pieces.30P
Twist-on Wire Connector, Black, high temperature wire connector wire range #22-#14. Made of rugged, thermoplastic polymer material 150 Degree C (302 Degree F) rated. Approved for circuit and fixture type connections up to 300 V only. For copper conductor only. Package of 100 pieces.Frequently Asked Questions
What is the color of the 31BK connector?
The 31BK connector is black in color.
What wire sizes does the 31BK support?
The ABB 31BK supports wire sizes from #18 to #14 AWG, including both solid and stranded copper wires.
Does the 31BK meet safety certifications?
Yes, the 31BK is UL and CSA certified for electrical insulation and safety standards.
Can the 31BK be used for stranded wires?
Yes, the 31BK is compatible with both solid and stranded copper wires in the #18-#14 AWG range.
Is the 31BK suitable for high-temperature applications?
Yes, the 31BK is rated for use in high-temperature environments up to 105°C.
