ABB - Installation Products 278-TB - Squeeze Connector, Straight, Trade Size 3-1/2 Inch, Knockout Size 3-1/2 Inch, Cable Range 3.200 to 4.370 Inch, Malleable Iron

ABB Installation Products 278-TB Squeeze Connector, Straight, Trade Size 3-1/2 Inch, Knockout Size 3-1/2 Inch, Cable…

UPC: 786209876171


Documents & Media
Specification SheetManufacturer Product Website

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB 278-TB Squeeze Connector, SKU 278-TB, is a heavy-duty malleable iron fitting engineered for secure terminations of flexible metal conduit (FMC), armored cable, and metal-clad cable in industrial and commercial electrical systems. Designed for trade size 3-1/2 inches with a matching 3-1/2-inch knockout size, this straight squeeze connector ensures precise alignment and a tight seal around cable diameters ranging from 3.200 to 4.370 inches. The connector features a robust malleable iron body with a zinc-plated finish for corrosion resistance and durability in harsh environments. It includes four steel screws for secure clamping and a steel locknut for stable mounting in electrical enclosures. The NPSM (National Pipe Straight Mechanical) male hub threads (3-1/2 - 8NPSM) provide compatibility with standard conduit systems, while the internal clamp design delivers consistent pressure to maintain electrical continuity and mechanical integrity. UL Standard 514B listed and certified to UL & cUL standards, the 278-TB is suitable for use in conduit systems where reliable grounding and bonding are required. Its large cable opening range accommodates a wide variety of cable types and sizes, reducing the need for multiple connector sizes on a project. Ideal for applications in manufacturing plants, data centers, commercial buildings, and infrastructure projects, the 278-TB simplifies installation by eliminating the need for specialized tools or complex assembly steps. The connector’s straightforward design ensures quick and repeatable installations, minimizing labor time and reducing the risk of installation errors. With a throat diameter of 3.425 inches and a clamp opening range optimized for 3-1/2-inch trade size, the 278-TB is a dependable solution for maintaining system integrity in high-performance electrical installations.
  • Trade size: 3-1/2 inches with 3-1/2-inch knockout compatibility
  • Cable range: 3.200 to 4.370 inches in diameter
  • Material: Malleable iron with zinc-plated finish for corrosion resistance
  • UL Standard 514B listed and UL & cUL certified for safety and reliability
  • Four steel screws and steel locknut for secure mounting and clamping

Specifications

Package Dimensions (L x W x H)
14 IN x 14 IN x 18 IN
Package Dimensions (L x W x H)
35.56 cm x 35.56 cm x 45.72 cm
Package Weight (Imperial)
4.5000 L
Package Weight (Metric)
2.0410 kg
Direct burial rated jacketed MC cable connector. Polyolefin coated zinc body. Concrete tight, raintight and listed for direct burial. For use with Jacketed Metal Clad Cables or TECK with O.D. of .50 to .61 inches.

895-DC2C

Direct burial rated jacketed MC cable connector. Polyolefin coated zinc body. Concrete tight, raintight and listed for direct burial. For use with Jacketed Metal Clad Cables or TECK with O.D. of .50 to .61 inches.
Straight Squeeze Type Connector, Conduit Size 3 Inches, Length 2-7/8 Inches, Width 3-13/16 Inches, Material Zinc Plated Malleable Iron, For use with Armored Cable/Flexible Metal Conduit

XC 408

Straight Squeeze Type Connector, Conduit Size 3 Inches, Length 2-7/8 Inches, Width 3-13/16 Inches, Material Zinc Plated Malleable Iron, For use with Armored Cable/Flexible Metal Conduit
Squeeze Connector, 90 Degree Bend, Trade Size 2-1/2 Inch, Knockout Size 2-1/2 Inch, Cable Range 2.520 to 3.100 Inch, Malleable Iron

282-TB

Squeeze Connector, 90 Degree Bend, Trade Size 2-1/2 Inch, Knockout Size 2-1/2 Inch, Cable Range 2.520 to 3.100 Inch, Malleable Iron
Squeeze Connector, 90 Degree Bend, Trade Size 4 Inch, Knockout Size 4 Inch, Cable Range 4.100 to 4.600 Inch, Malleable Iron

285-TB

Squeeze Connector, 90 Degree Bend, Trade Size 4 Inch, Knockout Size 4 Inch, Cable Range 4.100 to 4.600 Inch, Malleable Iron
Squeeze Connector, 90 Degree Bend, Trade Size 3 Inch, Knockout Size 3 Inch, Cable Range 3.100 to 3.640 Inch, Malleable Iron

283-TB

Squeeze Connector, 90 Degree Bend, Trade Size 3 Inch, Knockout Size 3 Inch, Cable Range 3.100 to 3.640 Inch, Malleable Iron
3/4 Inch Non-Metallic Sheathed Cable - Two Screw Connector with Slotted Head Screw, For Non-Metallic Sheathed Cables 8/2, 8/3 or 6/2, For Multiple (2) NM Cables 12/2 or 14/3, For Flexible Cords Cable Opening .530 Inch to .835 Inch, For Multiple Flexible Cords (.530 Combined Diameter Minimum) (2) 18/3 Minumum, For Service Entrance Cables Minimun Opening .395 Inch X .622 Inch

3303SL

3/4 Inch Non-Metallic Sheathed Cable - Two Screw Connector with Slotted Head Screw, For Non-Metallic Sheathed Cables 8/2, 8/3 or 6/2, For Multiple (2) NM Cables 12/2 or 14/3, For Flexible Cords Cable Opening .530 Inch to .835 Inch, For Multiple Flexible Cords (.530 Combined Diameter Minimum) (2) 18/3 Minumum, For Service Entrance Cables Minimun Opening .395 Inch X .622 Inch
Sheathed Cable Fitting, Straight, Knockout Size 1/2 Inch, Two Screw Connector with Slotted Screw, Steel with Zinc Plating

3302SL

Sheathed Cable Fitting, Straight, Knockout Size 1/2 Inch, Two Screw Connector with Slotted Screw, Steel with Zinc Plating
Metal-Clad and Armored Cable Fitting, Straight, Trade Size 2-1/2 Inch, Knockout Size 2-1/2 Inch, Cable Range 2.812 to 3.062 Inch, Malleable Iron with Zinc Plating, Nylon Insulated

3121-15

Metal-Clad and Armored Cable Fitting, Straight, Trade Size 2-1/2 Inch, Knockout Size 2-1/2 Inch, Cable Range 2.812 to 3.062 Inch, Malleable Iron with Zinc Plating, Nylon Insulated

Frequently Asked Questions

What is the cable range for the ABB 278-TB squeeze connector?

The ABB 278-TB squeeze connector is designed to accommodate cables within a range of 3.200 to 4.370 inches in diameter.

What material is the ABB 278-TB squeeze connector made from?

The ABB 278-TB squeeze connector is constructed from durable malleable iron, providing robust mechanical strength.

What are the trade and knockout sizes for the 278-TB connector?

The ABB 278-TB squeeze connector features a trade size of 3-1/2 inches and a knockout size of 3-1/2 inches.
