ABB - Installation Products 2043-2 - Tin Plated Copper, Threaded Transformer Stud Adapter for Stud to Cable Connections, Side 1 for Cable Size 350 kcmil Copper, Side 2 for Stud Size 1/2-13 UNC-2B. For Less than 1000 Volts. Length 3-1/8 inch, Diameter 7/8 inch. Installing Die TX 71 168 840.

ABB Installation Products 2043-2 Tin Plated Copper, Threaded Transformer Stud Adapter for Stud to Cable Connections, Side…

UPC: 075114409544

Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 50

Multiplier: 50

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB 2043-2 tin plated copper threaded transformer stud adapter provides a reliable, low-voltage connection between 350 kcmil copper cable and 1/2-13 UNC threaded studs in transformer installations. Engineered for systems operating under 1000 volts, this adapter features a 3-1/8 inch length and 7/8 inch diameter, ensuring compatibility with standard transformer configurations. The tin plating enhances corrosion resistance and improves electrical conductivity, making it ideal for long-term installations in industrial and utility environments. The threaded design allows for secure, vibration-resistant connections, reducing the risk of loosening over time. Compatible with ABB Installation Products' TX 71, 168, and 840 dies for proper installation, this adapter meets the demands of transformer secondary connections, distribution panels, and other low-voltage distribution systems. The copper construction ensures high conductivity and thermal stability, while the threaded interface simplifies field assembly and maintenance. For applications requiring a durable, low-resistance path between large copper conductors and transformer studs, the 2043-2 delivers consistent performance in compliance with electrical safety standards.
  • Tin plated copper construction for corrosion resistance and high conductivity
  • Threaded adapter for secure connections between 350 kcmil copper cable and 1/2-13 UNC studs
  • Rated for systems under 1000 volts for transformer and distribution applications
  • 3-1/8 inch length and 7/8 inch diameter for standard transformer configurations
  • Compatible with ABB TX 71, 168, and 840 installation dies

Specifications

Application
Stud to Cable Connections
Connection
Screw-On - Compression
Material
Tin Plated Copper
Size
Length 3-1.8 in , Diameter 7/8 in
Special Features
Threaded Stud 1/2-13 UNC-2B. Cable Size 350 kcmil Copper
Type
Threaded Transformer Stud Adapter for Stud to Cable
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
0.3000 L
Package Weight (Metric)
0.1360 kg
