ABB - Installation Products 2042-37 - Copper Tin-Plated Threaded Transformer Stud Adapter for NEMA pad-style connections - Twelve-hole transformer stud adapter, Silver Brazed Stud - Size 1-14 UNS-2B with 1.187 inch Outside Diameter. Pad 10.375 inch long x 3 inch wide x .375 inch thick. Two rows of 6 holes spaced 1.75 inch on center and .562 inch Diameter.

ABB Installation Products 2042-37 Copper Tin-Plated Threaded Transformer Stud Adapter for NEMA pad-style connections…

UPC: 783786380909


Documents & Media
Manufacturer Product Website

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB 2042-37 copper tin-plated threaded transformer stud adapter is a twelve-hole, silver-brazed stud designed for NEMA pad-style connections. This adapter features a 1-14 UNS-2B thread size with a 1.187-inch outside diameter, ensuring compatibility with standard transformer stud configurations. The unit measures 10.375 inches in length, 3 inches in width, and 0.375 inches in thickness, providing a robust platform for secure mounting. The adapter includes two rows of six holes, each spaced 1.75 inches on center with a 0.562-inch diameter. This design facilitates precise alignment and secure fastening of transformer components. The silver-brazed stud enhances electrical conductivity and corrosion resistance, making it suitable for industrial environments where reliability is critical. Ideal for transformer installations requiring NEMA pad-style connections, this adapter ensures consistent performance and long-term durability. The copper construction with tin plating provides excellent conductivity and resistance to oxidation, reducing maintenance requirements and improving system efficiency. Order by SKU 2042-37 from ABB - Installation Products for reliable transformer stud adapters.
  • Twelve-hole design for NEMA pad-style transformer connections
  • 1-14 UNS-2B thread size with 1.187" outside diameter
  • 10.375" x 3" x 0.375" dimensions with two rows of six holes
  • Holes spaced 1.75" on center with 0.562" diameter
  • Silver-brazed copper construction with tin plating for conductivity and corrosion resistance

Specifications

Application
NEMA Pad-Style Connections
Connection
Threaded
Connection Type
Threaded Transformer Stud Adapter
Finish
Tin Plated
Insulation
False
Material
Copper
Material
Copper Tin-Plated
Size
Pad 10.375 inch long x 3 inch wide x .375 inch thick
Special Features
NEMA Spacing of 1.75 inch Centers
Type
Threaded Transformer Adapter - Stud to Flat
Width
3 in
Width
76.2 mm
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
4.6200 L
Package Weight (Metric)
2.0960 kg
