ABB - Installation Products 15CA80RCH - Copper H-Tap Die for TBM15I/BPLT15BSCR- Connector CHT250214-8, CHT25014-7, CHT2502-6, Color Code Purple

ABB Installation Products 15CA80RCH Copper H-Tap Die for TBM15I/BPLT15BSCR- Connector CHT250214-8, CHT25014-7, CHT2502-6…

UPC: 786210904450


Documents & Media
Manufacturer Product Website

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB 15CA80RCH is a specialized copper H-tap die designed for use with ABB's TBM15I and BPLT15BSCR crimping tools. This die is engineered for reliable and efficient termination of copper conductors in H-tap configurations. Its specific application is to create secure and compliant connections for electrical distribution and transmission systems. The die is color-coded purple, a standard industry practice that aids in quick identification and proper tool setup, ensuring the correct die is used for specific connector types. This color coding is crucial for maintaining connection integrity and preventing errors during installation. The 15CA80RCH is compatible with ABB connector part numbers CHT250214-8, CHT25014-7, and CHT2502-6. These connectors are designed for various conductor sizes, and the purple die ensures the appropriate compression is applied for each. Proper application of this die results in a mechanically sound and electrically conductive joint, essential for the longevity and safety of electrical infrastructure. The SKU 15CA80RCH is part of ABB's extensive Installation Products catalog, known for its commitment to quality and performance in electrical connection solutions.
  • Designed for ABB TBM15I and BPLP15BSCR crimping tools
  • Compatible with ABB H-Tap connectors: CHT250214-8, CHT25014-7, CHT2502-6
  • Color-coded purple for easy identification and correct application
  • Ensures secure and reliable copper conductor terminations
  • Essential component for electrical distribution and transmission

Specifications

Color
Purple
Type
Copper H-Tap Die
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
0.6000 L
Package Weight (Metric)
0.2720 kg
