ABB Installation Products 15-231 Wire Pulling Lubricant, Semi-Synthetic Base, Freezing Point 25 Degrees F (-4 Degrees C)…
UPC: 783786152315
Contact for Pricing
Minimum Qty: 4
Multiplier: 4
*Contact for lower quantities*
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- Semi-synthetic base for effective lubrication
- Freezing point: 25°F (-4°C)
- High temperature stability: 200°F (93°C)
- Yellow color for visual application tracking
- 1-gallon container for professional use
Specifications
Application | Suitable for use with wire or cable insulated with rubber (R, RH, etc.), Neoprene, nylon and PVC plastics (T, TW, THW, THHN, etc.), Hypalon*, high density polyethylene and Cross Linked Polyethylene (XLP). Also compatible with high voltage cable having semi-conducting jackets |
Color | Yellow |
Container | Bucket |
Material | Semi-Synthetic |
Size | 1 Gallon |
Special Features | Polymer base formulation |
Type | Wire Pulling Lubricant |
Package Dimensions (L x W x H) | 7.3 IN x 7.3 IN x 7.75 IN |
Package Dimensions (L x W x H) | 18.542 cm x 18.542 cm x 19.685 cm |
Package Weight (Imperial) | 9.0000 L |
Package Weight (Metric) | 4.0820 kg |
Frequently Asked Questions
What is the coefficient of friction for this lubricant?
The coefficient of friction is 0.07 when sliding wet and 0.08 when sliding dry.
What types of insulation is this lubricant compatible with?
It is suitable for rubber, Neoprene, nylon, PVC plastics, Hypalon, high density polyethylene, and Cross Linked Polyethylene (XLP) insulated cables. It is also compatible with semiconducting jackets on high voltage cable.
What insulation types are not recommended for this lubricant?
This lubricant is not recommended for use on asbestos or low density polyethylene insulated cables.
What is the freezing point of this wire pulling lubricant?
The freezing point of this lubricant is +25°F (-4°C).
What is the high temperature stability of the lubricant?
The lubricant maintains high temperature stability up to 200°F (93°C).
What are the key properties of this wire pulling lubricant?
This lubricant is non-toxic, non-staining, and contains no silicones. It also has a pH of 7.9 and a yellow color.
What is the weight per gallon of the lubricant?
The weight per gallon of this wire pulling lubricant is 8.26 lbs.
What is the pH level of the lubricant?
The pH level of this wire pulling lubricant is 7.9.
Does this lubricant meet industry standards?
Yes, it meets ICEA Standards #S-61-402/NEMA Pub. #WC5 and #S-66-524/NEMA Pub. #WC7. It also has U.L. File E-43782.
Does this lubricant meet industry standards?
Yes, it meets ICEA Standards #S-61-402/NEMA Pub. #WC5 and #S-66-524/NEMA Pub. #WC7. It also has U.L. File E-43782.
How to Safely Use Wire Pulling Lubricant During Wiring Installation
This guide outlines the safe handling and application of wire pulling lubricant for various cable types in electrical conduit installations, emphasizing critical safety precautions.
Estimated time: 10m
Tools needed:
Protective gloves, Eye protection
Supplies needed:
Wire pulling lubricant
- Prepare for Lubricant Application
Wear protective gloves and eye protection before handling the lubricant. Avoid breathing mist or vapor during application. Wash thoroughly after handling the lubricant to prevent skin irritation or allergic reactions. Contaminated work clothing must not be allowed out of the workplace.
- Apply Lubricant to Approved Cables and Conduits
Apply the wire pulling lubricant to specified cable types including rubber, neoprene, nylon, polyvinylchloride, high density polyethylene, cross-linked polyethylene, and lead covered wire and cable (e.g., Types R, RH, RHH, RHW, T, TW, THW, THHN, THWN, HDPE, XLPE, and XHHW). Use the lubricant in steel, aluminum, and other approved conduits. Do not use this lubricant on asbestos or low density polyethylene insulated cables.
- Ensure Drying Before Energizing Circuits
After applying the lubricant and pulling wires, allow adequate drying time before energizing any circuits. The lubricant is conductive while still wet. Use great care to be certain that wet material does not come in contact with live or energized electrical parts or equipment. Failure to observe this warning may create an electrical shock hazard.
