ABB - Installation Products 11771 - 12 Ton Hex Die for Non-Insulated Terminal to fit 13642M and 13400 - Tubular Term, Terminal Size M, Wire Size 250 kcmil, Die Code 62

ABB Installation Products 11771 12 Ton Hex Die for Non-Insulated Terminal to fit 13642M and 13400 - Tubular Term…

UPC: 786210117713

Documents & Media
Manufacturer Product Website

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB 11771 is a 12-ton hexagonal die specifically engineered for crimping non-insulated terminals. This die, identified by Die Code 62, is designed to work with ABB's 13642M and 13400 series tools, ensuring compatibility and reliable performance within the ABB Installation Products ecosystem. Its primary application is with tubular terminals, and it is precisely calibrated for wire sizes up to 250 kcmil. The 12-ton rating signifies the significant force applied during the crimping process, which is crucial for creating secure and electrically sound connections. This die is essential for electrical contractors, maintenance professionals, and industrial electricians who require dependable termination solutions for large gauge conductors. The accurate crimp achieved with this die minimizes resistance, reduces the risk of connection failure, and contributes to the overall safety and efficiency of electrical systems. When paired with the correct ABB tool and compatible terminals, the 11771 die ensures a professional and lasting installation. Its robust construction is typical of ABB Installation Products, built for consistent operation in demanding environments. For applications requiring high-current capacity and reliable termination of 250 kcmil conductors, the ABB 11771 die provides the necessary crimping power and precision.
  • 12-ton crimping force for secure connections
  • Designed for non-insulated terminals
  • Compatible with ABB tools 13642M and 13400
  • Suitable for tubular terminals
  • Optimized for 250 kcmil wire size

Specifications

Capacity
12 ton
Size
Wire Size 250 kcmil
Type
Die
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
0.9000 L
Package Weight (Metric)
0.4080 kg
