ABB - Installation Products 11737 - 12 Ton Press Hex Installing Die - Use with Catalog Number 13400, Die Code 42, Copper Code 1/0 AWG, Flex/24 225/24, AL/CU #2 AWG, Color Code Pink

ABB Installation Products 11737 12 Ton Press Hex Installing Die - Use with Catalog Number 13400, Die Code 42, Copper…

UPC: 786210117379

Documents & Media
Manufacturer Product Website

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

This ABB 12 Ton Press Hex Installing Die, SKU 11737, is designed for efficient and reliable crimping operations. Specifically engineered for use with the ABB Catalog Number 13400 press, this die ensures precise terminations for various conductor types. The die code is 42, and it is color-coded pink for easy identification. This hex die is suitable for crimping copper conductors from 1/0 AWG up to Flex/24 225/24. It also accommodates AL/CU #2 AWG conductors. The 12-ton pressing capacity of the associated tool, when used with this die, provides the necessary force for secure and lasting connections. Key specifications include: * **Die Code:** 42 * **Color Code:** Pink * **Compatible Press:** ABB Catalog Number 13400 * **Copper Conductor Range:** 1/0 AWG, Flex/24 225/24 * **AL/CU Conductor Range:** #2 AWG * **Press Capacity:** 12 Ton This die is a critical component for electrical contractors and maintenance professionals requiring accurate and consistent crimps on medium to large gauge conductors. Its compatibility with a specific ABB press ensures optimal performance and adherence to industry standards for electrical connections.
  • 12 Ton Press Hex Installing Die
  • Die Code: 42
  • Color Code: Pink
  • For ABB Catalog Number 13400 Press
  • Handles 1/0 AWG Copper, Flex/24 225/24, AL/CU #2 AWG

Specifications

Capacity
12 ton
Color
Pink
Connection Type
Flex/24 225/24, AL/CU #2 AWG
Size
Copper Code 1/0 AWG, Flex/24 225/24, AL/CU #2 AWG
Type
Die
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
0.8000 L
Package Weight (Metric)
0.3630 kg
