ABB - Electrification TPLQ412RT - ReliaHome T-Series main lug load centers can be used as a home's main panel or sub panel depending upon your preferences. All ABB load centers are rated up to 60 degree/75 degree centrigrade and is suitable for use with service entrance equipment when installed in accordance with electrical code. The TPLQ412RT features space for 4, 1" breakers, a 125 A bus ampere rating, a factory included ground bar, and a plastic enclosure.
ABB - Electrification

TPLQ412RT

UPC: 783164681284

Documents & Media
Specification Sheet

Contact for Pricing

Overview

The ABB ReliaHome T-Series Main Lug Load Center (SKU: TPLQ412RT) is a compact, UL-listed electrical distribution solution designed for residential applications as either a main panel or sub-panel. Engineered by ABB Electrification, this load center delivers reliable performance with a 125A bus rating and space for four 1-inch circuit breakers, supporting up to 8 circuits. The TPLQ412RT features a durable plastic NEMA 1 enclosure rated for 60°C/75°C conductor temperatures, ensuring compatibility with standard wiring methods. It includes a factory-installed ground bar for simplified grounding and is suitable for single-phase, three-wire, 120/240V AC systems with a 22kAIC RMS symmetrical interrupting rating. This model is compliant with the National Electrical Code for service entrance applications and is distributed by Gross Automation. The TPLQ412RT is designed for flush mounting with the front cover included in the box, offering a space-efficient solution for modern homes. It can be used as a main panel or sub-panel depending on installation requirements, with all ABB load centers rated up to 60°C/75°C and suitable for service entrance equipment when installed in accordance with electrical code. The unit features space for four 1" breakers and a 125 A bus ampere rating, along with a factory-included ground bar for streamlined installation. The plastic enclosure ensures durability while meeting NEMA 1 standards. For main breaker conversion, compatible breaker kits (THQMHXXXF for 125A models) are available separately, allowing flexibility in system configuration. The load center is engineered for single-phase applications and supports standard wiring practices in residential settings.
  • 125A bus rating with space for 4 x 1" breakers (supports 8 circuits)
  • UL-listed (Panelboards No. 67) for single-phase, 120/240V AC systems
  • Rated 60°C/75°C for compatibility with standard wiring (6-2/0 AWG Cu-Al)
  • 22kAIC RMS symmetrical interrupting rating for safety and reliability
  • Plastic NEMA 1 enclosure with factory-installed ground bar

Specifications

Amperage Rating
125A
Amperage Rating
125 A
Connection Type
Main Lug
Current Rating
125 A
Enclosure
Indoor
Interrupt Rating
22
Load Regulation
120/240V ac
Material
Plastic
Mounting Type
Flush
Number Of Feeders
Either
Phase
1 Phase
Phase
1
Series
ReliaHome T-Series
Series
T-Series
Size
Space for 4, 1" breakers
Standard
UL
Voltage Rating
120/240 V ac
Wiring Configuration
3-Wire
Wiring Configuration
3 Wire
Package Dimensions (L x W x H)
9.563 IN x 7.813 IN x 5 IN
Package Dimensions (L x W x H)
24.29 cm x 19.845 cm x 12.7 cm
Package Weight (Imperial)
2.200 L
Package Weight (Metric)
0.998 kg
