ABB - Electrification TLQ510RT - ReliaHome T-Series main lug load centers can be used as a home's main panel or sub panel depending upon your preferences. All ABB load centers are rated up to 60 degree/75 degree centrigrade and is suitable for use with service entrance equipment when installed in accordance with electrical code. The TLQ510RT features space for 5, 1" breakers, a 100 A bus ampere rating, a factory included ground bar, and a outdoor suitable enclosure.
ABB - Electrification

TLQ510RT

UPC: 783164680188

Documents & Media
Specification Sheet

Contact for Pricing

Overview

The ABB Electrification ReliaHome T-Series TLQ510RT is a versatile main lug load center designed for reliable energy distribution in residential applications. This unit can serve as either a home's primary main panel or a sub-panel, offering flexibility to meet diverse installation requirements. Engineered for robust performance, all ABB T-Series load centers are rated for 60°C/75°C conductors and are suitable for use as service entrance equipment when installed in accordance with the National Electrical Code (NEC). The TLQ510RT features a compact design with space for five 1-inch circuit breakers, accommodating up to 10 circuits. Its 100 Ampere bus rating ensures ample capacity for typical residential power needs. This model comes with a factory-installed ground bar, simplifying installation and ensuring proper grounding. The enclosure is NEMA 3 rated, making it suitable for outdoor installations where protection against environmental elements is crucial. Key specifications include a single-phase, three-wire, 120/240V AC system voltage. The load center boasts a 22kAIC RMS symmetrical interrupting rating, providing a high level of protection against short circuits. ABB's T-Series load centers are UL listed (Panelboards No. 67) and are recognized for their safe, fast, and easy installation process, delivering intuitive design, function, and quality benefits. The TLQ510RT is an excellent choice for new construction or panel upgrades, offering durability and performance from a trusted manufacturer.
  • 100 Ampere bus rating
  • Accommodates five 1" circuit breakers (up to 10 circuits)
  • Factory-installed ground bar for simplified installation
  • NEMA 3 rated enclosure suitable for outdoor installations
  • UL listed (Panelboards No. 67)

Specifications

Amperage Rating
100A
Amperage Rating
100 A
Enclosure
Outdoor
Height
13.2 in;13.2 in
Interrupt Rating
22
Load Regulation
120/240V ac
Number Of Feeders
Top
Phase
1 Phase
Phase
1
Size
13.2 in
Standard
UL
Wiring Configuration
3 Wire
Wiring Configuration
3-Wire
Package Dimensions (L x W x H)
13.5 IN x 8.375 IN x 4.75 IN
Package Dimensions (L x W x H)
34.29 cm x 21.2725 cm x 12.065 cm
Package Weight (Imperial)
8.885 L
Package Weight (Metric)
4.030 kg
