ABB - Electrification THQL2125HID - HID breakers have been designed to handle the current and voltage spikes that result when gaseous discharge lamps, including fluorescent and HID lamps, are switched on and off. The THQL2125HID breaker features 2 poles, an ampere rating of 25 A, an interrupting rating of 10kAIC, and a voltage rating of 120/240V.
ABB - Electrification

THQL2125HID

UPC: 783164160116

Contact for Pricing

Overview

The ABB Electrification THQL2125HID is a 2-pole circuit breaker engineered specifically for High-Intensity Discharge (HID) and fluorescent lighting systems. It addresses the unique electrical demands of gaseous discharge lamps, which generate significant current and voltage spikes during startup and switching cycles. This breaker delivers robust overcurrent and short-circuit protection with a 25 Ampere (A) rating and a 10,000 Amperes Interrupting Current (10kAIC) rating at 120/240 Volts (V). Designed for compatibility with standard electrical systems, the THQL2125HID is ideal for industrial facilities, commercial buildings, and applications where HID or fluorescent lighting is prevalent. It prevents nuisance tripping and equipment damage caused by inrush currents associated with lamp switching, ensuring stable operation and extended lifespan of connected devices. The breaker is part of the THQB series, which is manufactured in the USA and adheres to stringent quality standards. Key specifications include: - 2 poles for balanced load distribution - 25A current rating for general power and lighting circuits - 120/240V voltage rating for common electrical systems - 10kAIC interrupting rating for fault current protection - Compatibility with fluorescent and HID lighting systems This model is a reliable choice for protecting downstream equipment in lighting circuits, reducing maintenance costs, and ensuring compliance with electrical safety standards.
  • 2-pole design for balanced load distribution in lighting circuits
  • 25A current rating suitable for general power and lighting applications
  • 120/240V voltage rating compatible with standard electrical systems
  • 10kAIC interrupting rating for robust fault current protection
  • Engineered to handle inrush currents from HID and fluorescent lamp switching

Specifications

Amperage Rating
25 A
Application
High Intensity Discharge Lighting
Current Rating
25 A
Frame
Q-Line
Interrupt Rating
10kA@120 Vac / 10kA@120/240 Vac
Interrupting Rating
10 kAIC
Load Rating
HACR
Number Of Poles
2
Poles
2
Series
THQL
Special Features
HID breakers have been designed to handle the current and voltage spikes that result when gaseous discharge lamps, including fluorescent and HID lamps, are switched on and off. The THQL2125HID breaker features 2 poles, an ampere rating of 25 A, an interrupting rating of 10kAIC, and a voltage rating of 120/240V.
Standard
E11592
Trip Range
Non-Interchangeable
Trip Range, Maximum
Non-Interchangeable
Trip Range, Minimum
Non-Interchangeable
Trip Type
LI
Voltage Rating
120/240 V
Package Dimensions (L x W x H)
2.5 IN x 2 IN x 3.25 IN
Package Dimensions (L x W x H)
6.35 cm x 5.08 cm x 8.255 cm
Package Weight (Imperial)
1.565 L
Package Weight (Metric)
0.710 kg
Ground Lug

DNGL

Ground Lug
INTERLOCK UNIT,AR-12M(SEPERATE),GMC(D)-6~16M

83411621001

INTERLOCK UNIT,AR-12M(SEPERATE),GMC(D)-6~16M
ZCT,LZR-030(V),EMPR,EXP

76512124011

ZCT,LZR-030(V),EMPR,EXP
JB5-2 2 POLE JUMPER 5.2MM SPACING

1SNK905302R0000

JB5-2 2 POLE JUMPER 5.2MM SPACING
JB5-5 5 POLE JUMPER 5.2MM SPACING

1SNK905305R0000

JB5-5 5 POLE JUMPER 5.2MM SPACING
One-hole, metric conductor, standard barrel with window lug, 4-6mm wire, M8 stud hole.

LCMA6-8-C

One-hole, metric conductor, standard barrel with window lug, 4-6mm wire, M8 stud hole.

Frequently Asked Questions

What voltage rating does the THQL2125HID support?

The THQL2125HID operates at a voltage rating of 120/240 Vac.

What is the interrupting rating of the THQL2125HID?

The THQL2125HID has an interrupting rating of 10,000 Amperes (10kAIC).

What is the current rating of the THQL2125HID?

The THQL2125HID has a current rating of 25 Amperes (25A).

Is the THQL2125HID suitable for HID lighting systems?

Yes, the THQL2125HID is specifically designed to protect HID and fluorescent lighting systems from inrush currents.

How many poles does the THQL2125HID have?

The THQL2125HID is a 2-pole circuit breaker.

Where is the THQL2125HID manufactured?

The THQL2125HID is manufactured in the USA by ABB Electrification.

What series does the THQL2125HID belong to?

The THQL2125HID is part of the THQB series.

Can the THQL2125HID protect against short circuits?

Yes, the THQL2125HID provides short-circuit protection with a 10kAIC rating.
