ABB - Electrification THQB1135 - Q line circuit breakers are one-inch wide per pole, compact, thermal-magnetic devices designed for residential and commercial applications. The QB breakers are bolt-on versions of the Q Line used for bolting to the bus connections of load centers and lighting panels. All Q Line circuit breakers feature Quick-make / Quick-break mechanisms, common trip bars, and easy to spot trip indication to ensure safety and reliability. Q Line breakers are available in 1, 2, and 3 pole versions, can be ordered with auxiliary contact and shunt trip accessories, and can be ordered for use in HID applications. 1135 Amps 35 A
ABB - Electrification

THQB1135

UPC: 783164059809

Contact for Pricing

Overview

The ABB Electrification Q Line THQB1135 circuit breaker is a compact, thermal-magnetic protection device engineered for demanding residential and commercial electrical distribution systems. This 1-pole, 35 Amp breaker is designed with a space-saving 1-inch width per pole, making it ideal for installations where panel density is a critical factor. As a bolt-on version of the renowned Q Line, the THQB1135 ensures a secure and reliable connection to the busbars of load centers and lighting panels, minimizing the risk of loose connections and electrical faults. Engineered for superior safety and operational efficiency, all Q Line circuit breakers, including the THQB1135, feature ABB's advanced Quick-make / Quick-break mechanisms. This technology provides rapid and decisive contact operation, significantly reducing arcing and extending the lifespan of the breaker. The integrated common trip bars across multi-pole configurations (though this is a 1-pole unit, the design philosophy is consistent) ensure that all poles trip simultaneously in the event of an overload or short circuit, enhancing system protection. Furthermore, the easy-to-spot trip indication offers immediate visual confirmation of a tripped breaker, simplifying troubleshooting and reducing downtime. The versatility of the Q Line extends to optional accessories. While the THQB1135 is a standard 1-pole unit, the Q Line series can be configured with auxiliary contacts for remote signaling and shunt trip accessories for remote tripping capabilities, allowing for integration into more complex control and monitoring systems. This breaker is also available for use in High-Intensity Discharge (HID) lighting applications, demonstrating its suitability for specialized commercial environments. Trust ABB Electrification for robust and reliable circuit protection solutions with the THQB1135 Q Line breaker.
  • ABB Q Line THQB1135 1-pole circuit breaker
  • 35 Amp current rating for reliable protection
  • Compact 1-inch width per pole for space efficiency
  • Bolt-on connection for secure busbar mounting
  • Quick-make / Quick-break mechanism for enhanced safety and durability

Specifications

Connection Type
Bolt-on
Current Rating
35 A
Poles
1-pole
Series
Q Line
Size
1-inch wide per pole
Special Features
Q line circuit breakers are one-inch wide per pole, compact, thermal-magnetic devices designed for residential and commercial applications. The QB breakers are bolt-on versions of the Q Line used for bolting to the bus connections of load centers and lighting panels. All Q Line circuit breakers feature Quick-make / Quick-break mechanisms, common trip bars, and easy to spot trip indication to ensure safety and reliability. Q Line breakers are available in 1, 2, and 3 pole versions, can be ordered with auxiliary contact and shunt trip accessories, and can be ordered for use in HID applications. 1135 Amps 35 A
Package Dimensions (L x W x H)
1 IN x 3.625 IN x 3.5 IN
Package Dimensions (L x W x H)
2.54 cm x 9.2075 cm x 8.89 cm
Package Weight (Imperial)
0.392 L
Package Weight (Metric)
0.178 kg
