ABB - Electrification THHQB1125GFT - Q line circuit breakers are one-inch wide per pole, compact, thermal-magnetic devices designed for residential and commercial applications. The QL breakers are plug-in versions of the Q Line used for connection to load centers and lighting panels. All Q Line circuit breakers feature Quick-make / Quick-break mechanisms, common trip bars, and easy to spot trip indication to ensure safety and reliability. Q Line breakers are available in 1, 2, and 3 pole versions, can be ordered with auxiliary contact and shunt trip accessories, and can be ordered for use in HID applications. 5GFT Amps 25 A
ABB - Electrification

THHQB1125GFT

UPC: 783164485523

Contact for Pricing

Overview

The ABB Q Line QL 25A 1-pole circuit breaker (SKU: THHQB1125GFT) delivers compact, reliable protection for residential and commercial electrical systems. Designed by ABB - Electrification, a global leader in power and automation technologies, this thermal-magnetic breaker features a one-inch width per pole, optimizing panel space without compromising performance. Engineered for seamless integration, the QL breaker is a plug-in version of the Q Line, ideal for load centers and lighting panels. Its Quick-make / Quick-break mechanism ensures rapid response during fault conditions, while the common trip bar provides coordinated protection across multi-pole configurations. The easy-to-spot trip indication enhances safety by enabling quick diagnostics. Available in 1, 2, and 3-pole versions, the QL breaker supports auxiliary contact and shunt trip accessories for expanded functionality. It is also compatible with HID applications, making it a versatile solution for diverse electrical environments. With a 25A rating, this breaker is built to meet the demands of modern electrical systems, offering durability and compliance with industry standards. ABB’s Q Line circuit breakers are trusted by professionals for their reliability, compact design, and advanced safety features. Whether for new installations or panel upgrades, the QL 25A breaker ensures efficient, dependable protection.
  • 1-inch wide per pole for space-efficient panel installation
  • Thermal-magnetic operation for reliable fault protection
  • Plug-in design for easy integration into load centers and lighting panels
  • Quick-make / Quick-break mechanism for rapid fault response
  • Available in 1, 2, and 3-pole versions with auxiliary/shunt trip accessories
  • Compatible with HID applications for versatile use
  • Easy-to-spot trip indication for quick diagnostics

Specifications

Amperage Rating
25A
Application
Model 3 Ground Fault Circuit Interrupter (GFCI)
Connection Type
Plug-in
Current Rating
25 A
Frame
Q-Line
Interrupt Rating
22kA@120 Vac
Load Rating
HACR
Number Of Poles
1
Poles
1, 2, or 3 pole versions
Series
Q Line
Size
1-inch per pole
Special Features
Q line circuit breakers are one-inch wide per pole, compact, thermal-magnetic devices designed for residential and commercial applications. The QL breakers are plug-in versions of the Q Line used for connection to load centers and lighting panels. All Q Line circuit breakers feature Quick-make / Quick-break mechanisms, common trip bars, and easy to spot trip indication to ensure safety and reliability. Q Line breakers are available in 1, 2, and 3 pole versions, can be ordered with auxiliary contact and shunt trip accessories, and can be ordered for use in HID applications. 5GFT Amps 25 A
Standard
E51075
Trip Range
Non-Interchangeable
Trip Range, Maximum
Non-Interchangeable
Trip Range, Minimum
Non-Interchangeable
Trip Type
LIG
Package Dimensions (L x W x H)
4 IN x 4.5 IN x 1.25 IN
Package Dimensions (L x W x H)
10.16 cm x 11.43 cm x 3.175 cm
Package Weight (Imperial)
0.570 L
Package Weight (Metric)
0.259 kg
