ABB - Electrification TEYD3025B - The TEY is a one-inch wide per pole, compact, "bolt-on" circuit breaker for use on grounded 480Y/277 Vac systems. The bolt-on mounting base accessory makes the TEY suitable for varied applications as a lug-lug breaker. All TEY circuit breakers feature Quick-make / Quick-break mechanisms, common trip bars, and easy to spot trip indication to ensure safety and reliability. TEYD breakers are available in 1, 2, and 3 pole versions 2&3 pole versions can be ordered with auxiliary contact, shunt trip, undervoltage release, or bell alarm accessories. 25A 3POLE 25KA 480/277 CKT BKR
ABB - Electrification

TEYD3025B

UPC: 783164461732

Contact for Pricing

Overview

The ABB TEYD3025B is a 3-pole, 25A thermal-magnetic circuit breaker designed for grounded 480Y/277V AC systems. Part of ABB’s TEYD series, it features a compact one-inch-per-pole bolt-on design with a 25kA interrupting rating at 480/277V, ensuring reliable protection in industrial and commercial panelboards. This breaker is UL listed and suitable for applications including lighting panels, HVAC systems, and motor circuits. Key specifications include: - **Current Rating:** 25A - **Poles:** 3 - **Interrupting Rating:** 25kA at 480/277V - **Voltage Rating:** 480Y/277V AC - **Mounting:** Bolt-on (compatible with TEY3B or TEY3B125 mounting bases for lug-lug applications) - **Wire Range:** #10–#4 AWG - **Trip Mechanism:** Thermal-magnetic with Quick-make/Quick-break operation - **Trip Indication:** Visible trip flag for fault diagnosis The TEYD3025B supports optional accessories for enhanced functionality, including auxiliary contacts (TEYXASL/TEYXASR), shunt trip (TEYXS1–TEYXS9), undervoltage release (TEYXU1–TEYXU9), and bell alarm (TEYXBA1). These accessories enable remote monitoring, automatic tripping, and audible fault notification, making the breaker adaptable to diverse system requirements. The breaker is also HACR rated for heating, air conditioning, and refrigeration applications, and UL listed for HID lighting circuits up to 50A. Ideal for space-constrained installations, the TEYD3025B integrates seamlessly with ABB’s A-Series lighting panels and other panelboard systems. Its non-interchangeable trip design ensures system integrity, while the bolt-on mounting base simplifies installation and replacement. Trusted for critical electrical distribution systems, the TEYD3025B delivers consistent performance and safety in demanding environments.
  • 25A, 3-pole thermal-magnetic circuit breaker for 480Y/277V AC systems
  • 25kA interrupting rating at 480/277V for reliable fault protection
  • Compact one-inch-per-pole bolt-on design for space-constrained installations
  • Compatible with TEY3B/TEY3B125 mounting bases for lug-lug applications
  • UL listed, HACR rated, and supports auxiliary contacts, shunt trip, and undervoltage release accessories

Specifications

Amperage Rating
25A
Application
Thermal Magnetic
Certifications
UL listed
Connection
#10-#4
Connection Type
Lug-lug
Current Rating
25 A
Current Rating
25A
Frame
TEYD
Interrupt Rating
65kA@120/240 Vac, 65kA@240 Vac,25kA@480Y/277 Vac
Interrupting Capacity
25kA
Mounting Type
Bolt-On
Number Of Poles
3
Poles
3
Series
TEY
Special Features
The TEY is a one-inch wide per pole, compact, "bolt-on" circuit breaker for use on grounded 480Y/277 Vac systems. The bolt-on mounting base accessory makes the TEY suitable for varied applications as a lug-lug breaker. All TEY circuit breakers feature Quick-make / Quick-break mechanisms, common trip bars, and easy to spot trip indication to ensure safety and reliability. TEYD breakers are available in 1, 2, and 3 pole versions 2&3 pole versions can be ordered with auxiliary contact, shunt trip, undervoltage release, or bell alarm accessories. 25A 3POLE 25KA 480/277 CKT BKR
Standard
E11592
Trip Range
Yes
Trip Range, Maximum
Yes
Trip Range, Minimum
Yes
Trip Type
LI
Voltage Rating
480/277 VAC
Voltage Rating
480Y/277 VAC
Package Dimensions (L x W x H)
5.375 IN x 3 IN x 3.5 IN
Package Dimensions (L x W x H)
13.6525 cm x 7.62 cm x 8.89 cm
Package Weight (Imperial)
3.250 L
Package Weight (Metric)
1.474 kg

Similar Products

TEYD3020B

Connection: #14-#10

Amperage Rating: 20A

Current Rating: 20 A

TEYD3015B

Connection: #14-#10

Amperage Rating: 15A

TEYD3035B

Amperage Rating: 35A

Current Rating: 35 A

Poles: 3P

TEYD3045B

Amperage Rating: 45A

Current Rating: 45 A

Color: Blue

TEYD3125B

Amperage Rating: 125A

Connection: #4-2/0

TEYD1025B

Interrupt Rating: 65kA@120 Vac, 65kA@120/240 Vac,25kA@277 Vac

Number Of Poles: 1
