Overview
- 25A current rating with 2-pole configuration for balanced protection
- 10kA interrupting capacity for superior short-circuit handling
- UL489 certified for compliance with North American safety standards
- Compact design for easy installation in panelboards and switchgear
- Rugged construction for long-term reliability in industrial environments
Specifications
Amperage Rating | 25 A |
Application | Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits. |
Current Rating | 25 A |
Number of Poles | 2 |
Poles | 2P |
Series | SU202M |
Size | 82x110x108mm |
Special Features | SU202M-C25 Miniature Circuit Breaker C-Char., 10kA, 25A, 2P UL489 |
Standard | CSA 22.2 No. 5 / IEC/EN 60947-2 / UL 489 |
Trip Type | C |
Tripping Characteristic | C |
Type | Contactors |
Voltage Rating | (480Y / 277 V AC) / (96 V DC) |
Package Dimensions (L x W x H) | 4.72 IN x 2.24 IN x 3.27 IN |
Package Dimensions (L x W x H) | 11.9888 cm x 5.6896 cm x 8.3058 cm |
Package Weight (Imperial) | 0.880 L |
Package Weight (Metric) | 0.399 kg |
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
ACS380-040S-07A2-4
ACS380 AC Drive, 3-380-480V In, 3HP, 6A, Type OPEN, 1.5 overload, Integrated, HxWxD 6.69x2.76x7.52 in, Module
XT2NU3090BFF000XXX
C.BREAKER TMAX XT2N 125 UL/CSA FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMA R 90 I3=450...900 A
Frequently Asked Questions
What is the maximum voltage rating for SU202M-C25?
The SU 200 M can handle voltages up to 480Y/277VAC and 96VDC.
What is the voltage rating for the SU 200 M?
The SU 200 M operates at voltages up to 480Y/277VAC and 96VDC.
Is the SU 200 M compatible with existing accessories?
Yes, the SU 200 M is fully compatible with existing UL489 System pro M compact accessories.
What safety features does the SU202M-C25 include?
It includes real contact position indication for safety and immediate system availability after a fault.
What is the rated breaking capacity of this circuit breaker?
The rated breaking capacity is 10 kA according to UL489 / CSA 22.2 No. 5 and 15 kA according to IEC / EN 60947-2.
Is the SU202M-C25 compatible with existing accessories?
Yes, the SU 200 M is fully compatible with existing UL489 System pro M compact accessories.
What is the rated breaking capacity of the SU 200 M?
The rated breaking capacity is 10 kA according to UL489 / CSA 22.2 No. 5 and 15 kA according to IEC / EN 60947-2.
What is the maximum amperage for the SU 200 M?
The SU 200 M is certified up to In = 40 A at 480 Y / 277 V AC.
What safety features does the SU 200 M have?
The SU 200 M features real contact position indication for safety and easy identification of the MCB's state.
How can I identify the SU 200 M product specifications?
Identification can be found in the product part numbering system on the face of the device, indicating poles, trip curve, and amperage.
