Contact for Pricing
Overview
- 20A current rating with 10kA interrupting capacity for robust protection
- K-characteristic trip curve ideal for motor and inductive loads
- Single-pole (1P) design for space-efficient panelboard installation
- UL489 certified for compliance with North American safety standards
- Compact form factor enables easy integration in residential and light commercial applications
Specifications
Amperage Rating | 20 A |
Amperage Rating, Maximum | 20 A |
Amperage Rating, Minimum | 20 A |
Application | Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits. |
Current Rating | 20 A |
Number of Poles | 1 |
Poles | 1P |
Series | SU201M |
Size | 82x110x108mm |
Special Features | SU201M-K20 Miniature Circuit Breaker K-Char., 10kA, 20A, 1P UL489 |
Standard | CSA 22.2 No. 5 / IEC/EN 60947-2 / UL 489 |
Trip Type | K |
Tripping Characteristic | K |
Type | Contactors |
Voltage Rating | (277 V AC) / (48 V DC) |
Package Dimensions (L x W x H) | 4.57 IN x 0.98 IN x 3.11 IN |
Package Dimensions (L x W x H) | 11.6078 cm x 2.4892 cm x 7.8994 cm |
Package Weight (Imperial) | 0.300 L |
Package Weight (Metric) | 0.136 kg |
Similar Products
SU201M-K40
Amperage Rating, Maximum: 40 A
Amperage Rating, Minimum: 40 A
Voltage Rating: (240 V AC) / (48 V DC)
SU201M-K50
Amperage Rating, Maximum: 50 A
Amperage Rating, Minimum: 50 A
Voltage Rating: (240 V AC) / (48 V DC)
You May Also Be Interested In
Frequently Asked Questions
What voltage range does the SU200M circuit breaker support?
The SU 200 M miniature circuit breaker supports voltages up to 480Y/277VAC and 96VDC. It is designed for universal use in AC and DC applications.
What is the rated breaking capacity of the circuit breaker?
The SU 200 M has a rated breaking capacity of 10 kA according to UL489 / CSA 22.2 No. 5 and 15 kA according to IEC / EN 60947-2.
What is the maximum certified amperage for this circuit breaker?
The SU 200 M is certified up to 40 A at 480Y / 277V AC according to UL 489 / CSA 22.2 No.5.
What terminal specifications does the circuit breaker have?
The SU 200 M features IP 20 finger-safe terminals with cylinder lift twin terminals that accept 35 mm² and 10 mm² wires or busbars.
What accessories are available for the SU200M circuit breaker?
Accessories include auxiliary contacts, signal contacts, shunt trips, and busbar systems. Only one side mount accessory per MCB is allowed for UL/CSA applications.
