ABB - Electrification S803S-B13 - The S803S-B13 is a 3-pole High Performance Circuit breaker with B-characteristic, with cage terminal and a rated current of 6 A. It is a current limiting device with a maximum breaking capacity of 50kA at 240/415V. It can be used for voltages up to 400/690V and in DC as well. It has two different tripping mechanisms, the thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. The S803S-B13 complies with IEC/EN 60898-1 and IEC/EN 60947-2 and allows the use for residential, commercial and industrial applications. It has numerous of approvals, therefore it can be used worldwide. The extensive range of accessory makes the use of S803S-B13 more comfortable. Due to the fast arc extinction of S803S-B13 your application will be secured.
ABB - Electrification

S803S-B13

Documents & Media
Manufacturer Product Website

Contact for Pricing

Overview

The ABB S803S-B13 is a 3-pole High Performance Circuit Breaker, engineered for robust electrical protection across residential, commercial, and industrial applications. Featuring a B-characteristic trip curve, this device is ideal for circuits where moderate inrush currents are expected. With a rated current of 6 A, it provides reliable overload and short-circuit protection. The S803S-B13 is a current-limiting device, boasting a substantial maximum breaking capacity of 50 kA at 240/415 V, ensuring safety even under severe fault conditions. Its operational voltage range extends up to 400/690 V AC and is also suitable for DC applications, offering significant versatility. Protection is managed by two distinct tripping mechanisms: a thermal tripping mechanism for safeguarding against overloads and an electromechanical tripping mechanism for instantaneous response to short circuits. Manufactured by ABB - Electrification, this circuit breaker adheres to stringent international standards, including IEC/EN 60898-1 and IEC/EN 60947-2, and carries numerous global approvals, facilitating worldwide installation. The S803S-B13 is designed for DIN rail mounting and features cage terminals for secure connections. Its fast arc extinction capability further enhances application security. The extensive range of compatible accessories allows for enhanced usability and customization, making the S800S series a flexible and dependable choice for critical electrical infrastructure. The compact design with a small pole width of only 27 mm contributes to space-saving installations. It is UL 1077 recognized (UL file #E76126 and E167556) as a supplemental protective device, offering an additional layer of safety. The S803S-B13 is CE certified and marked, underscoring its compliance with European safety directives. Its multi-function terminals and suitability for reverse feed add to its practical installation benefits. The fast breaking time, typically between 2.3–2.5 ms, minimizes damage during fault events.
  • 3-pole circuit breaker with B-characteristic
  • Rated current of 6 A
  • Maximum breaking capacity of 50 kA at 240/415 V
  • Suitable for AC voltages up to 400/690 V and DC applications
  • Dual thermal and electromechanical tripping mechanisms for comprehensive protection

Specifications

Amperage Rating
13 A
Application
Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits.
Connection Type
cage terminal
Current Rating
6 A
Interrupt Rating
(240 V AC) 30 kA / (480Y / 277 V AC) 14 kA / (600Y / 347 V AC) 6 kA
Number of Poles
3
Poles
3
Series
S803S
Size
82x110x108mm
Special Features
The S803S-B13 is a 3-pole High Performance Circuit breaker with B-characteristic, with cage terminal and a rated current of 6 A. It is a current limiting device with a maximum breaking capacity of 50kA at 240/415V. It can be used for voltages up to 400/690V and in DC as well. It has two different tripping mechanisms, the thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. The S803S-B13 complies with IEC/EN 60898-1 and IEC/EN 60947-2 and allows the use for residential, commercial and industrial applications. It has numerous of approvals, therefore it can be used worldwide. The extensive range of accessory makes the use of S803S-B13 more comfortable. Due to the fast arc extinction of S803S-B13 your application will be secured.
Standard
RoHs, CSA, cUL, CE, GOST
Standard
IEC/EN 60947-2 / IEC/EN 60898-1 / UL 1077
Trip Type
B
Type
Contactors
Voltage Rating
(240 V AC) / (480Y / 277 V AC) / (600Y / 347 V AC)
Voltage Rating
400/690 VAC
Package Dimensions (L x W x H)
3.39 IN x 4.13 IN x 3.9 IN
Package Dimensions (L x W x H)
8.6106 cm x 10.4902 cm x 9.906 cm
Package Weight (Imperial)
1.700 L
Package Weight (Metric)
0.771 kg
